2011 Trek 520

Original specifications: Shimano Deore LX · 9-speed rear derailleur · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #22633
Model year
2011
Category
City & Commuter
Original MSRP
$1,369.99
Sizes
48cm, 51cm, 54cm, 57cm, 60cm
Colors
Root Beer
In this record
22 specifications · archived image · original MSRP
Model history 22 other years

Browse other years

Compare side by side

Identification clues

2011 archived details

Published colors
Root Beer
Frame
CroMo
Original equipment
Comfort Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildCroMo · Comfort Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

5 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

48cm51cm54cm57cm60cm

Published colors

Root Beer
View 5 archived size/color combinations
SizeColor
48cmRoot Beer
51cmRoot Beer
54cmRoot Beer
57cmRoot Beer
60cmRoot Beer

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialCroMo
Fork MaterialCromo, single crown

Drivetrain

Component GroupComfort Mix
ShiftersShimano Dura-Ace
Front DerailleurShimano Deore LX
Rear DerailleurShimano Deore LX
CranksetShimano trekking M543, 26/36/48 teeth
CassetteShimano HG50
Rear Cogs9-speed, 11 - 32 teeth
PedalsShimano M520

Brakes

BrakesAvid SD5 brakes, Tektro RL340 levers

Cockpit & Contact Points

Headset1 1/8" threadless
HandlebarBontrager Race VR
Handlebar ExtensionsNot included
StemBontrager Race Lite
SaddleBontrager Select City
SeatpostBontrager Alloy

Wheels & Tires

HubsShimano Deore LX
RimsBontrager Camino
Front Tire700 x 32c Bontrager Race Lite Hardcase
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes48/36/26T · 11–32T · 9-speed
Lowest0.81:1 Highest4.36:1 Total range537%
Estimated speed At 90 RPM Lowest gear5.9 mph Highest gear31.6 mph

Uses front tire 700C×32; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
700 x 32c Bontrager Race Lite Hardcase
Cassette · Original
Shimano HG50
Pedals · Original
Shimano M520
More parts (9)Fewer parts
Saddle · Original
Bontrager Select City
Crankset · Original
Shimano trekking M543

26/36/48 teeth

Front derailleur · Original
Shimano Deore LX
Rear derailleur · Original
Shimano Deore LX
Shifters · Original
Shimano Dura-Ace Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Handlebar · Original
Bontrager Race VR
Stem · Original
Bontrager Race Lite
Rims · Original
Bontrager Camino
Hubs · Original
Shimano Deore LX

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 32c Bontrager Race Lite Hardcase
Drivetrain
9-speed
Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 9 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: · Cromo, single crown

Archived: Group: Comfort Mix · Shifters: Shimano Dura-Ace · Front derailleur: Shimano Deore LX · Rear derailleur: Shimano Deore LX · Crankset: Shimano trekking M543, 26/36/48 teeth · Cassette: Shimano HG50 · Rear cogs: 9-speed, 11 - 32 teeth

Archived: Brakes: Avid SD5 brakes, Tektro RL340 levers

Archived: Wheel size: 700c wheels · Rims: Bontrager Camino · Hubs: Shimano Deore LX · Front tire: 700 x 32c Bontrager Race Lite Hardcase

Controls and contact points

Archived: Headset: 1 1/8" threadless · Handlebar: Bontrager Race VR · Stem: Bontrager Race Lite · Seatpost: Bontrager Alloy · Saddle: Bontrager Select City · Pedals: Shimano M520
