Original specifications: 14.99 kg (33 lb, 0.8 oz) published weight · geometry for 6 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900001137Browse other years
Compare side by side
2026 archived details
Clues, not proof of model year. Colors vary and components may have been replaced.
| Frame Construction | Specialized E5 Premium Aluminum frame, front/rear thru-axles, fully integrated down tube battery, internal cable routing, fender/rack mounts, 12x142mm, flat-mount disc brakes |
|---|---|
| Frame Material | Aluminum |
| Fork | Future Shock 2.0 w/Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount |
| Fork Material | Carbon Fiber |
| Shifters | SRAM Apex 12-speed |
|---|---|
| Rear Derailleur | SRAM Apex Eagle 12-speed |
| Crankset | SRAM Alloy Crankset, DUB interface |
| Cassette | SRAM PG-1210 Eagle, 12-speed, 11-50t |
| Chain | SRAM NX Eagle, 12-speed |
| Brakes | (F) SRAM Apex, Hydraulic disc / (R) SRAM Apex, hydraulic disc |
|---|
| Handlebar | Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare |
|---|---|
| Stem | Future Stem, Comp |
| Saddle | Body Geometry Power Sport, steel rails |
| Seatpost | Carbon, single-bolt, 27.2mm |
| Wheels | (F) DT G540 Disc Asvn / (R) DT G540 Disc Asvn |
|---|---|
| Front Tire | Pathfinder TLR Fast Gravel Tire 700x40c, GRIPTON T2/T5 |
| Rear Tire | Pathfinder TLR Fast Gravel Tire 700x40c, GRIPTON T2/T5 |
| Motor | Specialized 1.2 SL Custom Lightweight Motor |
|---|---|
| Battery | Specialized SL1-320, fully integrated, 320Wh |
| Display/Remote | Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote |
| Charger | Custom charger, 48V System w/ SL system charger plug |
No specifications match. Try a component name or clear your search.
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
| Measurement | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Seat tube | 390 mm | 430 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Effective top tube | 529 mm | 542 mm | 558 mm | 566 mm | 588 mm | 604 mm |
| Head tube | 99 mm | 104 mm | 116 mm | 133 mm | 159 mm | 185 mm |
| Head-tube angle | 70° | 70.5° | 71.25° | 72° | 72° | 72° |
| Seat-tube angle | 74° | 73.75° | 73.5° | 73.5° | 73.5° | 73.5° |
| Chainstay / rear center | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1035 mm | 1041 mm | 1048 mm | 1058 mm | 1075 mm | 1093 mm |
| Bottom-bracket drop | 80 mm | 80 mm | 78 mm | 78 mm | 76 mm | 76 mm |
| Bottom-bracket height | 270 mm | 270 mm | 272 mm | 272 mm | 275 mm | 275 mm |
| Reach | 365 mm | 374 mm | 383 mm | 392 mm | 401 mm | 410 mm |
| Stack | 571 mm | 577 mm | 590 mm | 608 mm | 630 mm | 655 mm |
| Fork offset / rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Front center | 607 mm | 614 mm | 620 mm | 629 mm | 646 mm | 664 mm |
| Trail | 61 mm | 57 mm | 57 mm | 58 mm | 69 mm | 66 mm |
| Fork length / axle-to-crown | 389 mm | 389 mm | 389 mm | 389 mm | 389 mm | 389 mm |
| Crank length | 165 mm | 170 mm | 172.5 mm | 172.5 mm | 175 mm | 175 mm |
| Stem length | 60 mm | 70 mm | 80 mm | 90 mm | 100 mm | 100 mm |
| Handlebar width | 380 mm | 400 mm | 420 mm | 420 mm | 440 mm | 440 mm |
Dimensions as recorded.
Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.
Your changes apply to this calculation. The archived build stays unchanged.
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
12-speed

Replacement option
single-bolt, 27.2mm

Replacement option
GRIPTON T2/T5
Replacement search: 700cx40 bicycle tire Before ordering: Check rim type and tire clearance.DUB interface
103mm drop x 70mm reach x 12º flare
Based on the original build. Check fit and installed parts before ordering.
Archived specifications for reference. Check the fitted parts before ordering.
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Archived: Frame: Specialized E5 Premium Aluminum frame, front/rear thru-axles, fully integrated down tube battery, internal cable routing, fender/rack mounts, 12x142mm, flat-mount disc brakes · Fork: Future Shock 2.0 w/Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount · Carbon Fiber
Archived: Shifters: SRAM Apex 12-speed · Rear derailleur: SRAM Apex Eagle 12-speed · Crankset: SRAM Alloy Crankset, DUB interface · Cassette: SRAM PG-1210 Eagle, 12-speed, 11-50t · Chain: SRAM NX Eagle, 12-speed
Archived: Brakes: (F) SRAM Apex, Hydraulic disc / (R) SRAM Apex, hydraulic disc
Archived: Wheels: (F) DT G540 DISC ASVN / (R) DT G540 DISC ASVN · Front tire: Pathfinder TLR Fast Gravel Tire 700x40c, GRIPTON T2/T5 · Rear tire: Pathfinder TLR Fast Gravel Tire 700x40c, GRIPTON T2/T5
Archived: Handlebar: Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare · Stem: Future Stem, Comp · Seatpost: Carbon, single-bolt, 27.2mm · Saddle: Body Geometry Power Sport, steel rails
Archived: Motor: Specialized 1.2 SL Custom Lightweight Motor · Battery: Specialized SL1-320, fully integrated, 320Wh · Display: Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote · Charger: Custom charger, 48V System w/ SL system charger plug
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
