2022 Salsa Stormchaser GRX 810 1x SUS

Cyclocross/Gravel bicycle from the Velopedia specification archive.

Share owner experience

Original MSRP: $3,549.00
Sizes: 49cm, 52.5cm, 54.5cm, 56cm, 57.5cm, 59cm, 61cm
Colors: Black
Weight: 24 lbs. 13 oz. for 56cm
Geometry: 7 manufacturer sizes · Ride analysis
Archive ID: 900000611

Learn more about Salsa →

Current market

Snapshot not yet available

Protected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.

Move, scroll, tap or type to start the protected update.

Have you owned this bike?Help preserve its real-world history by sharing your owner experience.

Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.

Display name Required Email address Required · private Ownership Required When or how long you owned it Required Frame size Required Primary type of riding Required Rider height Optional

Overall owner experience Required · at least 120 characters

Fit and sizing observations Optional Long-term strengths Optional Problems or recurring maintenance Optional Parts replaced or upgraded Optional What a used buyer should inspect Optional Would you own one again? Optional

After submitting, use the verification link sent to your email. Nothing appears publicly until Velopedia approves it.

Already contributed? Send me a fresh private edit link

For privacy, Velopedia shows the same confirmation whether or not an experience exists.

Manufacturer catalog

Published sizes and colors

7 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

49cm52.5cm54.5cm56cm57.5cm59cm61cm

Published colors

Black

Frameset

Frame Construction	Stormchaser
Frame Material	Aluminum
Fork	RockShox Rudy XPLR Base, 40 mm, 51 mm offset

Drivetrain

Shifters	Shimano GRX RX810-LA
Front Derailleur	N/A
Rear Derailleur	Shimano GRX RX812
Crankset	Race Face Ride, 38t
Cassette	Shimano SLX M7000, 11–42t, 11-speed
Chain	Shimano HG601

Brakes

Brakes	Brake Calipers: Shimano GRX RX810; Rotors: Shimano RT 64 (Center Lock, 160 mm)

Cockpit & Contact Points

Headset	FSA No.42 ACB
Handlebar	Salsa Cowchipper Deluxe
Stem	Salsa Guide
Saddle	WTB Volt Medium Steel SL
Seatpost	TranzX YSP38J, 90 x 360 mm

Wheels & Tires

Front Tire	Teravail Rutland 700c x 47 mm, tubeless-ready, Durable casing
Rear Tire	Teravail Rutland 700c x 47 mm, tubeless-ready, Durable casing
Wheel Size	700C; 650B

Size-specific frame data

Geometry

7 sizes · 16 measurements

Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.

Measurement	49cm	52.5cm	54.5cm	56cm	57.5cm	59cm	61cm
Seat tube	390 mm	440 mm	475 mm	510 mm	520 mm	545 mm	570 mm
Effective top tube	508 mm	529 mm	548 mm	563 mm	578 mm	593 mm	608 mm
Head tube	90 mm	105 mm	125 mm	145 mm	165 mm	185 mm	205 mm
Head-tube angle	69.2°	69.2°	69.2°	69.2°	69.2°	69.2°	69.2°
Seat-tube angle	74.4°	73.2°	72.2°	72.2°	72.2°	72.2°	72.3°
Chainstay / rear center	435 mm	435 mm	435 mm	435 mm	435 mm	435 mm	435 mm
Wheelbase	1023.1 mm	1032.8 mm	1041.5 mm	1057.6 mm	1073.7 mm	1089.8 mm	1107.1 mm
Bottom-bracket drop	64 mm	64 mm	64 mm	64 mm	64 mm	64 mm	64 mm
Reach	358.6 mm	363 mm	364.8 mm	373.9 mm	383 mm	392.1 mm	643.5 mm
Stack	535.2 mm	549.3 mm	568.1 mm	586.9 mm	605.8 mm	624.6 mm	643.5 mm
Standover height	696.5 mm	736 mm	765.6 mm	794.3 mm	806.9 mm	829.1 mm	851.2 mm
Fork offset / rake	51 mm	51 mm	51 mm	51 mm	51 mm	51 mm	51 mm
Fork length / axle-to-crown	433 mm	433 mm	433 mm	433 mm	433 mm	433 mm	433 mm
Crank length	165 mm	165 mm	170 mm	170 mm	175 mm	175 mm	175 mm
Stem length	60 mm	70 mm	80 mm	90 mm	90 mm	100 mm	110 mm
Handlebar width	400 mm	420 mm	440 mm	460 mm	480 mm	500 mm	520 mm

Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.

Geometry interpretation

What this geometry means

Choose a size

56cm geometry

Riding position

The 586.9 mm stack is tall relative to the 373.9 mm reach, leaving room for a more upright, relaxed gravel position. The 72.2° seat angle is relatively relaxed, shifting the seated position rearward and effectively lengthening the cockpit compared with a steeper seat-tube layout.

Handling tendencies

A 69.2° head angle combined with a 1057.6 mm wheelbase points to calm and stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.

Archive context

The seat angle of 72.2° sits toward the more relaxed end. Its bottom-bracket drop of 64 mm sits toward the shallower-drop end. The head angle of 69.2° sits somewhat slacker than typical.

Compared with 22 distinct cyclocross/gravel geometries in the Medium-equivalent size cohort from model years 2022–2024 in the Velopedia archive.

Across the size range

From 49cm to 61cm, reach grows by 284.9 mm and stack by 108.3 mm, showing how the frame becomes both longer and taller through the published size range. The rear center stays essentially constant at about 435 mm across sizes, so most of the wheelbase growth happens in the front half of the bike rather than by lengthening the rear triangle.

Geometry describes frame proportions and likely tendencies, not a ride test. Rider proportions, cockpit setup, tires, suspension settings, wheel configuration, and component choices can materially change how a bicycle fits and feels.
