Velopedia Bicycle Archive
2004 Jamis Nova
Cyclocross bicycle from the Velopedia specification archive.
- Original MSRP
- $1,049.95
- Sizes
- 46cm, 49cm, 51cm, 53cm, 55cm, 57cm, 60cm
- Colors
- Slate/Matte Black
- Weight
- 23
- Archive ID
- 92426
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Reynolds 631 |
| Fork | Kinesis Crosslight |
| Fork Material | Aluminum/chrome-moly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Shimano Tiagra Triple |
|---|---|
| Shifters | Shimano Tiagra STI Dual Control |
| Front Derailleur | Shimano Tiagra Triple, bottom-pull/clamp-on 28.6mm |
| Rear Derailleur | Shimano Tiagra GS |
| Crankset | TruVativ Elita, 30/42/52 teeth |
| Bottom Bracket | TruVativ ISIS Drive SL, 118mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 12 - 25 teeth |
| Chain | Shimano CN-HG72, 1/2 x 3/32" |
| Pedals | Ritchey Logic Pro V-3 |
Brakes
| Brakes | Avid Shorty 4 brakes, Shimano Tiagra STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Dia-Compe SAS |
|---|---|
| Handlebar | Ritchey Biomax II |
| Handlebar Extensions | Not included |
| Stem | Ritchey Comp |
| Saddle | Fi'zi:k Pave, chrome-moly rails |
| Seatpost | Ritchey Pro Road V2, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano Tiagra |
|---|---|
| Rims | Mavic MA3, 36-hole |
| Spokes | Stainless steel, 14/15ga. (2.0/1.8mm) double-butted |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 30c Hutchinson ProSeries Gold Elite |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
