2027 Trek Verve 2 Lowstep
Original specifications: Shimano CUES, 9-speed drivetrain · 700c wheels · M - 13.80 kg / 30.43 lbs published weight.
Selling this bike? Create a shareable bike record
At a glance
- Model year
- 2027
- Category
- Hybrid
- Original MSRP
- $799.99
- Sizes
- XS, S, M, L
- Colors
- Blue Sage, Era White
- Weight
- M - 13.80 kg / 30.43 lbs
- Geometry
- 4 manufacturer sizes
- In this record
- 23 specifications · 8 archived images · original MSRP · geometry
- Archive ID
- 900000775
Model history 1 other year
Original buildAluminum · Shimano CUES, 9-speed · 700c
Frameset
| Frame Construction | Alpha Gold Aluminum, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR |
|---|---|
| Frame Material | Aluminum |
| Fork | Verve alloy, steel steerer, internal brake routing, 460mm axle-to-crown, ThruSkew |
| Fork Material | Aluminum |
Drivetrain
| Component Group | Shimano CUES, 9-speed |
|---|---|
| Shifters | Shimano U4000, 9 speed |
| Rear Derailleur | Shimano CUES U4000 |
| Crankset | ProWheel Pro alloy, 40T narrow-wide steel ring, 170mm length |
| Bottom Bracket | Sealed cartridge, 68mm |
| BB Shell Width | 68 mm |
| Cassette | Shimano LINKGLIDE LG300, 11-46, 9 speed |
| Chain | KMC X Glide, 11-speed, gray |
| Pedals | Bontrager City pedals |
Brakes
| Brakes | Tektro HD-M275 hydraulic disc |
|---|
Cockpit & Contact Points
| Handlebar | XS, S, M: Bontrager alloy, 31.8mm, comfort sweep, 620mm width / L: Bontrager alloy, 31.8mm, comfort sweep, 660mm width |
|---|---|
| Stem | XS, S: Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 85mm length / M, L: Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 105mm length |
| Saddle | Bontrager Boulevard |
| Seatpost | Alloy, adjustable suspension, 27.2mm, 300mm length |
Wheels & Tires
| Hubs | (F) Formula DC-20, alloy, 6-bolt, 100x5mm / (R) Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm |
|---|---|
| Rims | Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve |
| Front Tire | Bontrager H2 Comp, wire bead, 30 tpi, 700x45mm |
| Rear Tire | Bontrager H2 Comp, wire bead, 30 tpi, 700x45mm |
| Wheel Size | 700c |
Geometry
Frame measurements by size.
Published frame view
Select an available measurement to locate it on the frame.
All geometry measurements4 sizes · 15 measurements
| Measurement | XS | S | M | L |
|---|---|---|---|---|
| Seat tube | 350 mm | 440 mm | 500 mm | 550 mm |
| Effective top tube | 546 mm | 568 mm | 594 mm | 604 mm |
| Head tube | 140 mm | 160 mm | 170 mm | 180 mm |
| Head-tube angle | 70.5° | 70.5° | 70.5° | 70.5° |
| Seat-tube angle | 74.5° | 73.5° | 72° | 72° |
| Chainstay / rear center | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1080 mm | 1096 mm | 1105 mm | 1110 mm |
| Bottom-bracket drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Bottom-bracket height | 301 mm | 301 mm | 301 mm | 301 mm |
| Reach | 375 mm | 380 mm | 385 mm | 392 mm |
| Stack | 615 mm | 634 mm | 644 mm | 653 mm |
| Standover height | 631 mm | 654 mm | 682 mm | 694 mm |
| Fork offset / rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 81 mm | 81 mm | 81 mm | 81 mm |
| Wheel size | 700c | 700c | 700c | 700c |
Measurements may vary by configuration, wheel size, or frame setting where noted in the published chart.
Gearing
Lower ratios provide more mechanical advantage for climbing. Higher ratios turn the rear wheel farther with each crank revolution.
Parts & serviceability
Find replacement parts

45NRTH Gravdal Studded Wire Bead Clincher Tire , 700x45
700x45
Replacement option · verify fit

Challenge Getaway XP Tubeless Tire Black, 700x45
700x45
Replacement option · verify fit
More parts (4)

Redshift Sports ShockStop Suspension Seatpost Black, 27.2x350mm, 35mm Travel
27.2x350mm, 35mm Travel
Replacement option · verify fit

Cane Creek eeSILK Plus Alloy Suspension Seatpost Black, 27.2mm
27.2mm
Replacement option · verify fit
Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases.
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Trek Verve 2 Lowstep · Hybrid · Published sizes: XS, S, M, L
Frame and fork
Inspect the frame and fork →Archived: Frame: Alpha Gold Aluminum, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR · Fork: Verve alloy, steel steerer, internal brake routing, 460mm axle-to-crown, ThruSkew · Aluminum
Drivetrain
Check drivetrain wear →Archived: Group: Shimano CUES, 9-speed · Shifters: Shimano U4000, 9 speed · Rear derailleur: Shimano CUES U4000 · Crankset: ProWheel Pro alloy, 40T narrow-wide steel ring, 170mm length · Bottom bracket: Sealed cartridge, 68mm · Cassette: Shimano LINKGLIDE LG300, 11-46, 9 speed · Chain: KMC X Glide, 11-speed, gray
Brakes
Inspect the brakes →Archived: Brakes: Tektro HD-M275 hydraulic disc
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c · Rims: Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve · Hubs: (F) Formula DC-20, alloy, 6-bolt, 100x5mm / (R) Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm · Front tire: Bontrager H2 Comp, wire bead, 30 tpi, 700x45mm · Rear tire: Bontrager H2 Comp, wire bead, 30 tpi, 700x45mm
Controls and contact points
Archived: Handlebar: XS, S, M: Bontrager alloy, 31.8mm, comfort sweep, 620mm width / L: Bontrager alloy, 31.8mm, comfort sweep, 660mm width · Seatpost: Alloy, adjustable suspension, 27.2mm, 300mm length · Saddle: Bontrager Boulevard · Pedals: Bontrager City pedals
Before and during the test ride
Follow the full used-bike inspection order →Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery8 images
Checking current listings…
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
