Uses front tire 26×2; rear size isn’t listed.
Velopedia Bicycle Archive
2011 Trek 820
Original specifications: Shimano mix drivetrain · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #22667- Model year
- 2011
- Category
- Mountain
- Original MSRP
- $349.99
- Sizes
- 13", 16", 18", 19.5", 21", 22.5"
- Colors
- Gloss Black
- In this record
- 23 specifications · archived image · original MSRP
Model history 21 other years
Browse other years
Compare side by side
Identification clues
2011 archived details
- Published colors
- Gloss Black
- Frame
- Steel
- Original equipment
- Shimano mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildSteel · Shimano mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Steel |
| Fork | SR Suntour M-2025, 63mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | Shimano mix |
|---|---|
| Shifters | Shimano EF40 |
| Front Derailleur | Shimano TX51 |
| Rear Derailleur | Shimano TX31 |
| Crankset | Hawk DX, 28/38/48 teeth |
| Cassette | Shimano TZ31 |
| Rear Cogs | 7-speed, 13 - 34 teeth |
| Pedals | Wellgo Nylon Platform |
Brakes
| Brakes | Tektro V brakes, Shimano EF40 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Semi integrated |
|---|---|
| Handlebar | Bontrager Approved Riser |
| Handlebar Extensions | Not included |
| Stem | Bontrager Approved |
| Saddle | Bontager SSR |
| Seatpost | Bontrager SSR, 31.6mm diameter |
Wheels & Tires
| Hubs | Front: Formula FM21, Rear: Formula FM31 |
|---|---|
| Rims | Bontrager 550, 36-hole |
| Front Tire | 26 x 2.0" Bontrager LT3 |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
31.6mm diameter
Shimano EF40 levers
More parts (2)Fewer parts
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.0" Bontrager LT3
- Drivetrain
- 7-speed
- Seatpost diameter
- 31.6 mm
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: SR Suntour M-2025, 63mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: SR Suntour M-2025, 63mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Shimano mix · Shifters: Shimano EF40 · Front derailleur: Shimano TX51 · Rear derailleur: Shimano TX31 · Crankset: Hawk DX, 28/38/48 teeth · Cassette: Shimano TZ31 · Rear cogs: 7-speed, 13 - 34 teeth
Brakes
Inspect the brakes →Archived: Brakes: Tektro V brakes, Shimano EF40 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Bontrager 550, 36-hole · Hubs: Front: Formula FM21, Rear: Formula FM31 · Front tire: 26 x 2.0" Bontrager LT3
Controls and contact points
Archived: Headset: 1 1/8" threadless Semi integrated · Handlebar: Bontrager Approved Riser · Stem: Bontrager Approved · Seatpost: Bontrager SSR, 31.6mm diameter · Saddle: Bontager SSR · Pedals: Wellgo Nylon Platform
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
