2001 Trek 8500

Original specifications: Shimano XTR · 9-speed · mechanical rear derailleur · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #35722
Model year
2001
Category
Mountain
Original MSRP
$1,649.99
Sizes
S, M, L, XL
Colors
Gloss Black, Red
Geometry
Legacy reference
In this record
23 specifications · archived image · original MSRP · geometry
Model history 11 other years

Browse other years

Compare side by side

Identification clues

2001 archived details

Published colors
Gloss Black, Red
Frame
Alpha SL aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAlpha SL aluminum · Mountain Mix

Manufacturer catalog

Published sizes and colors

4 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMLXL

Published colors

Gloss BlackRed

Frameset

Frame ConstructionTIG-welded
Frame MaterialAlpha SL aluminum
ForkRock Shox Sid XC, 3.15" travel
Fork MaterialAluminum/magnesium, triple-clamp crown

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore XT RapidFire SL
Front DerailleurShimano Deore XT
Rear DerailleurShimano XTR SGS
CranksetBontrager Race, 22/32/44 teeth
Rear Cogs9-speed, 11 - 32 teeth
Chain1/2 x 3/32"
PedalsBontrager Re-Entry

Brakes

BrakesAvid Single Digit 5 brakes, Shimano Deore XT RapidFire SL levers

Cockpit & Contact Points

Headset1 1/8" threadless Dia-Compe SAS
HandlebarBontrager Race Modified
Handlebar ExtensionsNot included
StemBontrager Race
SaddleBontrager FS 2000
SeatpostBontrager Race

Wheels & Tires

HubsRolf Dolomite
RimsFront: Rolf Dolomite, Rear: Rolf Dolomite Assymetric
SpokesDT stainless steel, 2.0mm double-butted
Front TireBontrager Super-X

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube586.7 mm
Head-tube angle71°
Seat-tube angle73°
Chainstay / rear center424.2 mm
Wheelbase1064.3 mm
Fork offset / rake43.2 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes44/32/22T · 11–32T · 9-speed
Lowest0.69:1 Highest4.00:1 Total range582%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Pedals · Original
Bontrager Re-Entry
Saddle · Original
Bontrager FS 2000
Crankset · Original
Bontrager Race

22/32/44 teeth

More parts (6)Fewer parts
Front derailleur · Original
Shimano Deore XT
Rear derailleur · Original
Shimano XTR SGS
Shifters · Original
Shimano Deore XT RapidFire SL
Handlebar · Original
Bontrager Race Modified
Stem · Original
Bontrager Race
Seatpost · Original
Bontrager Race

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Bontrager Super-X
Drivetrain
9-speed
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Rock Shox Sid XC, 3.15" travel · Aluminum/magnesium, triple-clamp crown

Archived: Fork: Rock Shox Sid XC, 3.15" travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore XT RapidFire SL · Front derailleur: Shimano Deore XT · Rear derailleur: Shimano XTR SGS · Crankset: Bontrager Race, 22/32/44 teeth · Rear cogs: 9-speed, 11 - 32 teeth · Chain: 1/2 x 3/32"

Archived: Brakes: Avid Single Digit 5 brakes, Shimano Deore XT RapidFire SL levers

Archived: Rims: Front: Rolf Dolomite, Rear: Rolf Dolomite Assymetric · Hubs: Rolf Dolomite · Front tire: Bontrager Super-X

Controls and contact points

Archived: Headset: 1 1/8" threadless Dia-Compe SAS · Handlebar: Bontrager Race Modified · Stem: Bontrager Race · Seatpost: Bontrager Race · Saddle: Bontrager FS 2000 · Pedals: Bontrager Re-Entry
