2002 Sun Bicycles Key West

Original specifications: 26" wheels · 41 lb published weight.

Share owner experience

At a glance

Archive #91243

Model year: 2002
Category: Cruiser
Original MSRP: $269.00
Sizes: 21", womens 17"
Colors: Black, Blue, Dark Green, Red
Weight: 41 lb
In this record: 23 specifications · archived image · original MSRP

Model history 5 other years

Browse other years

Compare side by side

Identification clues

2002 archived details

Published colors: Black, Blue, Dark Green, Red
Frame: Hi-tensile steel, oversize
Original equipment: N/A

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildHi-tensile steel, oversize · 26" wheels

Manufacturer catalog

Published sizes and colors

2 sizes · 4 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

21"womens 17"

Published colors

BlackBlueDark GreenRed

Frameset

Frame Construction	Brazed/welded
Frame Material	Hi-tensile steel, oversize
Fork Material	Hi-tensile steel, unicrown crown

Drivetrain

Shifters	SRAM MRX
Rear Derailleur	Shimano Tourney TY-22
Crankset	1-piece 6 1/2", 44 teeth
Bottom Bracket	One piece
BB Shell Width	American
Rear Cogs	7-speed, 14 - 28 teeth
Chain	KMC Z410, 1/2 x 3/32"
Pedals	Wellgo LU-990

Brakes

Brakes	Tektro linear-pull brakes, linear-pull levers

Cockpit & Contact Points

Headset	1" steel
Handlebar	Steel
Stem	Steel
Saddle	Viscount 2350
Seatpost	Steel, 25.4mm diameter

Wheels & Tires

Hubs	Steel, nutted
Rims	Aluminum, 32-hole
Spokes	Stainless steel, 14ga. (2.0mm) straight gauge
Spoke Nipples	Brass nipples
Front Tire	26 x 2.125" Kenda
Wheel Size	26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

Published build44T · 14–28T · 7-speed

Lowest1.57:1 Highest3.14:1 Total range200%

Estimated speed At 90 RPM Lowest gear11.1 mph Highest gear22.1 mph

Uses front tire 26×2.125; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

26 x 2.125" Kenda Replacement search: 26x2.125 bicycle tire Before ordering: Check rim type and tire clearance.

Search Amazon Search eBay

Brake pads · Original

Tektro linear-pull brakes

linear-pull levers

Search Amazon Search eBay

Pedals · Original

Wellgo LU-990

Search Amazon Search eBay

More parts (2)Fewer parts

Rear derailleur · Original

Shimano Tourney TY-22

Search eBay

Seatpost · Original

Steel

25.4mm diameter

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 26 x 2.125" Kenda
Drivetrain: 7-speed
Seatpost diameter: 25.4 mm
Bottom bracket / shell: One piece · American

Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Brazed/welded · Fork: · Hi-tensile steel, unicrown crown

Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.

Drivetrain

Check drivetrain wear →

Archived: Shifters: SRAM MRX · Rear derailleur: Shimano Tourney TY-22 · Crankset: 1-piece 6 1/2", 44 teeth · Bottom bracket: One piece · Rear cogs: 7-speed, 14 - 28 teeth · Chain: KMC Z410, 1/2 x 3/32"

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Tektro linear-pull brakes, linear-pull levers

Inspect pads, cables and housings, then examine both rim braking surfaces for concavity, cracking or heavy wear. Confirm each caliper returns and centers correctly.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 26" wheels · Rims: Aluminum, 32-hole · Hubs: Steel, nutted · Front tire: 26 x 2.125" Kenda

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Controls and contact points

Archived: Headset: 1" steel · Handlebar: Steel · Stem: Steel · Seatpost: Steel, 25.4mm diameter · Saddle: Viscount 2350 · Pedals: Wellgo LU-990

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
