Velopedia Bicycle Archive

2013 Scott Sub 10

Original specifications.

Share owner experience

At a glance

Archive #9239706

Model year: 2013
Category: City & Commuter
Sizes: XS, S, M, L, XL
Colors: Yellow
In this record: 16 specifications · archived image

Model history 7 other years

Browse other years

Compare side by side

Identification clues

2013 archived details

Published colors: Yellow
Frame: Aluminum

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XSSMLXL

Published colors

Yellow

Frameset

Frame Material	Aluminum
Fork	Scott SUB

Drivetrain

Shifters	Shimano Alfine RapidFire
Crankset	Shimano 46t
Bottom Bracket	Shimano Octalink
Cassette	Gates CDC-MP 24t
Rear Cogs	1x8 Speeds
Chain	Gates Belt
Pedals	VP 615

Brakes

Brakes	Shimano M446

Cockpit & Contact Points

Headset	1 1/8" Threadless
Handlebar	Syncros UC2.5
Stem	Syncros UC2.5
Saddle	Sub SC30
Seatpost	Syncros UC2.5

Wheels & Tires

Front Tire	Continental Sport Contact

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Original size / build

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Bottom bracket · Original

Shimano Octalink

Search Amazon Search eBay

Crankset · Original

Shimano 46t

Search eBay

Shifters · Original

Shimano Alfine RapidFire Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.

Search eBay

More parts (3)Fewer parts

Handlebar · Original

Syncros UC2.5

Search eBay

Stem · Original

Syncros UC2.5

Search eBay

Seatpost · Original

Syncros UC2.5

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Continental Sport Contact
Bottom bracket / shell: Shimano Octalink

Equipment inspection checks 8 checks based on 4 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Aluminum · Fork: Scott SUB

Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Shifters: Shimano Alfine RapidFire · Crankset: Shimano 46t · Bottom bracket: Shimano Octalink · Cassette: Gates CDC-MP 24t · Rear cogs: 1x8 Speeds · Chain: Gates Belt

Shift the hub through its complete range using the correct procedure. Check cable or electronic actuation, axle security, hub-shell condition and any sign of lubricant leakage.
Inspect the belt teeth and edges for damage, verify alignment and tension, and check that any frame split or belt-tensioning hardware is secure.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Shimano M446

Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Controls and contact points

Archived: Headset: 1 1/8" Threadless · Handlebar: Syncros UC2.5 · Stem: Syncros UC2.5 · Seatpost: Syncros UC2.5 · Saddle: SUB SC30 · Pedals: VP 615

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
