2006 Schwinn Mesa

Original specifications: Mountain Mix drivetrain · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #11387
Model year
2006
Category
Mountain
Original MSRP
$349.99
Sizes
15", 17", 19", 21"
Colors
Pearl Black/Peral Indigo
In this record
26 specifications · original MSRP
Model history 10 other years

Browse other years

Compare side by side

Identification clues

2006 archived details

Published colors
Pearl Black/Peral Indigo
Frame
N'Litened Gold Label aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildN'Litened Gold Label aluminum · Mountain Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

4 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

15"17"19"21"

Published colors

Pearl Black/Peral Indigo
View 4 archived size/color combinations
SizeColor
15"Pearl Black/Peral Indigo
17"Pearl Black/Peral Indigo
19"Pearl Black/Peral Indigo
21"Pearl Black/Peral Indigo

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialN'Litened Gold Label aluminum
ForkSR Suntour XCT, 80mm travel
Fork MaterialAluminum

Drivetrain

Component GroupMountain Mix
ShiftersSRAM SX-4
Front DerailleurSRAM 3.0, top-pull/clamp-on 31.8mm
Rear DerailleurSRAM SX4
CranksetTruvativ X-Flow, 22/32/44 teeth
Bottom BracketTruvativ cartridge, 113mm spindle
BB Shell Width68mm English
Rear Cogs8-speed, 11 - 32 teeth
ChainKMC Z72
PedalsResin

Brakes

BrakesTektro aluminum linear-pull brakes, Tektro 2-finger levers

Cockpit & Contact Points

Headset1 1/8" threadless FPD
HandlebarMesa
StemSchwinn Ride Tuned
SaddleSchwinn Anatomic
SeatpostAluminum micro-adjust, 26.8mm diameter

Wheels & Tires

HubsFront: JY aluminum, Rear: JY aluminum cassette
RimsJalco, 32-hole
SpokesStainless steel, 14ga. (2.0mm) straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.10" WTB Velociraptor
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes44/32/22T · 11–32T · 8-speed
Lowest0.69:1 Highest4.00:1 Total range582%
Estimated speed At 90 RPM Lowest gear4.8 mph Highest gear28.1 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC Z72
Front tire · Original
26 x 2.10" WTB Velociraptor
Brake pads · Original
Tektro aluminum linear-pull brakes

Tektro 2-finger levers

More parts (2)Fewer parts
Shifters · Original
SRAM SX-4
Seatpost · Original
Aluminum micro-adjust

26.8mm diameter

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" WTB Velociraptor
Drivetrain
8-speed
Seatpost diameter
26.8 mm
Bottom bracket / shell
Truvativ cartridge, 113mm spindle · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: SR Suntour XCT, 80mm travel · Aluminum

Archived: Fork: SR Suntour XCT, 80mm travel

Archived: Group: Mountain Mix · Shifters: SRAM SX-4 · Front derailleur: SRAM 3.0, top-pull/clamp-on 31.8mm · Rear derailleur: SRAM SX4 · Crankset: Truvativ X-Flow, 22/32/44 teeth · Bottom bracket: Truvativ cartridge, 113mm spindle · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z72

Archived: Brakes: Tektro aluminum linear-pull brakes, Tektro 2-finger levers

Archived: Wheel size: 26" wheels · Rims: Jalco, 32-hole · Hubs: Front: JY aluminum, Rear: JY aluminum cassette · Front tire: 26 x 2.10" WTB Velociraptor

Controls and contact points

Archived: Headset: 1 1/8" threadless FPD · Handlebar: Mesa · Stem: Schwinn Ride Tuned · Seatpost: Aluminum micro-adjust, 26.8mm diameter · Saddle: Schwinn Anatomic · Pedals: Resin
