Velopedia Bicycle Archive
2002 Raleigh C30
Hybrid bicycle from the Velopedia specification archive.
- Original MSRP
- $279.99
- Sizes
- 15", 17", 19", 21", 23", womens 16", womens 19"
- Colors
- Silver, Silver/Green
- Archive ID
- 91287
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Raleigh |
| Fork Material | Hi-tensile steel, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Hybrid Mix |
|---|---|
| Shifters | Shimano Revo |
| Front Derailleur | Shimano Tourney TY-32, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano C050 |
| Crankset | Shimano Tourney TY-30A, 28/38/48 teeth |
| Bottom Bracket | Sealed cartridge, 122mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 7-speed freewheel, 13 - 34 teeth |
| Chain | KMC Z-51, 1/2 x 3/32" |
| Pedals | Resin, platform |
Brakes
| Brakes | Tektro 836A Linear Pull brakes, Tektro 385A levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" steel |
|---|---|
| Handlebar | Steel, 2" rise |
| Handlebar Extensions | Not included |
| Stem | Aluminum, adjustable |
| Saddle | Velo Comfort |
| Seatpost | Aluminum, suspension, 27.2mm diameter |
Wheels & Tires
| Hubs | Joy Tech aluminum, Q/R |
|---|---|
| Rims | Weinmann 519, 36-hole |
| Spokes | Sha-Dar stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 38c Kenda K-830 |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
