Lowest0.69:1
Highest4.00:1
Total range582%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.14; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Marin Pine Mountain
Original specifications: Shimano LX drivetrain · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #16383- Model year
- 2007
- Category
- Mountain
- Original MSRP
- $1,709.00
- Sizes
- 13", 15", 17", 19", 20.5", 22"
- Colors
- Gloss Copper
- In this record
- 26 specifications · archived image · original MSRP
Model history 14 other years
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Gloss Copper
- Frame
- Double-butted Columbus Zona Chromoly
- Original equipment
- Shimano LX
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildDouble-butted Columbus Zona Chromoly · Shimano LX · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Double-butted Columbus Zona Chromoly |
| Fork | Fox 32 F100R, 100mm |
| Fork Material | Magnesium/aluminum, single crown |
Drivetrain
| Component Group | Shimano LX |
|---|---|
| Shifters | Shimano LX |
| Front Derailleur | Shimano LX |
| Rear Derailleur | Shimano XT |
| Crankset | TruVativ Stylo XR, 22/32/44 teeth |
| Bottom Bracket | TruVativ GXP |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Shimano CN-HG73 |
| Pedals | Shimano PD-M520 |
Brakes
| Brakes | Avid Juicy 3 brakes, Avid Hydraulic Disc levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless TH-857 |
|---|---|
| Handlebar | Double Butted 6061 Alloy riser |
| Handlebar Extensions | Not included |
| Stem | FSA OS150 |
| Saddle | WTB Laser V Comp |
| Seatpost | FSA SL-K, 27.2mm diameter |
Wheels & Tires
| Hubs | WTB LaserDisc Lite |
|---|---|
| Rims | WTB LaserDisc Lite, 32-hole |
| Spokes | WTB stainless steel, 15/17ga. (1.8/1.7mm) butted |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 2.14" WTB MotoRaptor |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
FSA SL-K
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (8)Fewer parts
Shimano PD-M520
WTB Laser V Comp
Shimano LX
Shimano XT
Shimano LX
FSA OS150
WTB LaserDisc Lite
32-hole
WTB LaserDisc Lite
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.14" WTB MotoRaptor
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- TruVativ GXP
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fox 32 F100R, 100mm · Magnesium/aluminum, single crown
Suspension
Evaluate the suspension →Archived: Fork: Fox 32 F100R, 100mm
Drivetrain
Check drivetrain wear →Archived: Group: Shimano LX · Shifters: Shimano LX · Front derailleur: Shimano LX · Rear derailleur: Shimano XT · Crankset: TruVativ Stylo XR, 22/32/44 teeth · Bottom bracket: TruVativ GXP · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG73
Brakes
Inspect the brakes →Archived: Brakes: Avid Juicy 3 brakes, Avid Hydraulic Disc levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: WTB LaserDisc Lite, 32-hole · Hubs: WTB LaserDisc Lite · Front tire: 26 x 2.14" WTB MotoRaptor
Controls and contact points
Archived: Headset: 1 1/8" threadless TH-857 · Handlebar: Double Butted 6061 Alloy riser · Stem: FSA OS150 · Seatpost: FSA SL-K, 27.2mm diameter · Saddle: WTB Laser V Comp · Pedals: Shimano PD-M520
