2000 Marin Pine Mountain

Archived: Frame: TIG-welded · Fork: Answer Manitou SX-R, 3.15" travel · Aluminum/magnesium, triple-clamp crown

• Inspect the complete frame for cracks, dents, distortion, heavy abrasion, suspicious paint differences or evidence of a previous repair.

Archived: Fork: Answer Manitou SX-R, 3.15" travel

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Archived: Group: Mountain Mix · Shifters: Shimano Deore LX RapidFire SL · Front derailleur: Shimano Deore LX · Rear derailleur: Shimano Deore XT SGS · Crankset: Shimano Deore LX · Bottom bracket: Shimano BB-LP27 · Rear cogs: 9-speed, 11 - 32 teeth · Chain: SRAM PC-59, 1/2 x 3/32"

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Avid 1D-20 brakes, Avid SD-1.9 L levers

• Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Archived: Rims: Mavic X221, 32-hole · Hubs: Shimano Deore LX · Front tire: IRC Notos XC

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Archived: Headset: Tange Seiki DX-2 · Handlebar: Aluminum · Stem: Ovation butted alloy · Seatpost: Marin Comp, 27.0mm diameter · Saddle: WTB SSTX2 · Pedals: Victor VP-106

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
