2026 Kona LBF
Original manufacturer specifications including 29" wheels, geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2026
- Category
- Gravel & Cyclocross
- Original MSRP
- $3,699.00
- Sizes
- S, M, L, XL
- Colors
- Gloss Emerald w/ Shades of Jade Decals
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 22 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001963
Frameset
| Frame Construction | Reynolds 520 Butted Cromoly |
|---|---|
| Fork | RockShox SID 100mm 29" |
| Rear Shock | n/a |
Drivetrain
| Front Derailleur | n/a |
|---|---|
| Rear Derailleur | SRAM Apex |
| Crankset | SRAM X1 32T / S-M 170mm / L-XL 175mm |
| Bottom Bracket | SRAM DUB BSA 73 |
| Cassette | SRAM GX 10-52t 12spd |
| Chain | SRAM NX |
| Pedals | n/a |
Brakes
| Brakes | Brake Calipers: SRAM G2 4P; Front Brake Rotor: SRAM HS2 180mm 6B; Rear Brake Rotor: SRAM HS2 180mm 6B; Brake Levers: SRAM Apex |
|---|
Cockpit & Contact Points
| Headset | FSA no.9M ZS44/EC44 |
|---|---|
| Handlebar | Ritchey Beacon Comp / S 46cm / M 50cm / L-XL 52cm |
| Stem | Ritchey Comp Trail / S 35mm / M 45mm / L-XL 60mm |
| Saddle | WTB Volt |
| Seatpost | TranzX Dropper +RAD Internal 31.6mm / S 125mm / M 150mm / L-XL 170mm |
Wheels & Tires
| Hubs | (F) Formula 15x110mm / (R) Formula 12x148mm XD |
|---|---|
| Rims | RaceFace ARC 27 Offset |
| Spokes | Stainless 2.0mm Black |
| Front Tire | Maxxis Dissector 29x2.4" |
| Rear Tire | Maxxis Forekaster 29x2.4" |
| Wheel Size | 29" |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Seat tube | 400 mm | 445 mm | 490 mm | 535 mm |
| Top tube | 552 mm | 577 mm | 607 mm | 647 mm |
| Head tube | 90 mm | 110 mm | 130 mm | 150 mm |
| Head-tube angle | 67° | 67° | 67° | 67° |
| Seat-tube angle | 75° | 75° | 75° | 75° |
| Chainstay / rear center | 440-456 | 440-456 | 440-456 | 440-456 |
| Wheelbase | 1099-1115 | 1127-1142 | 1160-1176 | 1203-1219 |
| Bottom-bracket drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Bottom-bracket height | 305 mm | 305 mm | 305 mm | 305 mm |
| Reach | 385 mm | 405 mm | 430 mm | 465 mm |
| Stack | 623 mm | 642 mm | 660 mm | 679 mm |
| Standover height | 748 mm | 783 mm | 816 mm | 849 mm |
| Fork offset / rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Front center | 670 mm | 697 mm | 730 mm | 773 mm |
| Fork length / axle-to-crown | 511 mm | 511 mm | 511 mm | 511 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
The archived table contains multiple manufacturer geometry states. Velopedia preserves source order and analyzes each state separately rather than averaging the published values.
S geometry
Configuration
Archive context: The head angle of 67° sits toward the slacker end. Its stack of 623 mm sits toward the taller end. Its wheelbase of 1099 mm sits toward the longer end.
Compared with 81 distinct cyclocross/gravel geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S · Configuration 1 geometry Archive context: The head angle of 67° sits toward the slacker end. Its wheelbase of 1115 mm sits toward the longer end. Its stack of 623 mm sits toward the taller end.
Compared with 81 distinct cyclocross/gravel geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S · Configuration 2 geometry M geometry
Configuration
Archive context: The head angle of 67° sits toward the slacker end. The seat angle of 75° sits toward the steeper end. Its stack of 642 mm sits toward the taller end.
Compared with 93 distinct cyclocross/gravel geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M · Configuration 1 geometry Archive context: The head angle of 67° sits toward the slacker end. Its wheelbase of 1142 mm sits toward the longer end. The chainstay of 456 mm sits toward the longer rear-center end.
Compared with 93 distinct cyclocross/gravel geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M · Configuration 2 geometry L geometry
Configuration
Archive context: The head angle of 67° sits toward the slacker end. The seat angle of 75° sits toward the steeper end. Its wheelbase of 1160 mm sits toward the longer end.
Compared with 66 distinct cyclocross/gravel geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L · Configuration 1 geometry Archive context: The head angle of 67° sits toward the slacker end. Its wheelbase of 1176 mm sits toward the longer end. The chainstay of 456 mm sits toward the longer rear-center end.
Compared with 66 distinct cyclocross/gravel geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L · Configuration 2 geometry XL geometry
Configuration
Archive context: The head angle of 67° sits toward the slacker end. The seat angle of 75° sits toward the steeper end. Its wheelbase of 1203 mm sits toward the longer end.
Compared with 71 distinct cyclocross/gravel geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL · Configuration 1 geometry Archive context: The head angle of 67° sits toward the slacker end. Its wheelbase of 1219 mm sits toward the longer end. The chainstay of 456 mm sits toward the longer rear-center end.
Compared with 71 distinct cyclocross/gravel geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL · Configuration 2 geometry Parts & serviceability
Find replacement parts
SRAM NX
Interpreted as SRAM NX · 12-speed Named component · published drivetrain speed — verify exact version
SRAM GX 10-52t 12spd
Interpreted as SRAM GX · 12-speed Component family — verify exact version
Maxxis Dissector 29x2.4"
Named tire and published size
More qualified parts (4)
Maxxis Forekaster 29x2.4"
Named tire and published size
SRAM DUB BSA 73
Named archived component — verify dimensions
WTB Volt
Named archived component — verify exact version
SRAM Apex
Interpreted as SRAM Apex · 12-speed Named component · published drivetrain speed — verify exact version
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameCheck paint chips, vent holes and the inside of the seat tube for corrosion. Also look for dents, bent tubes and cracking around welded or brazed joints.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 12-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Kona LBF · Cyclocross/Gravel · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Reynolds 520 Butted Cromoly · Fork: RockShox SID 100mm 29"
Suspension
Evaluate the suspension →Archived: Fork: RockShox SID 100mm 29"
Drivetrain
Check drivetrain wear →Archived: Rear derailleur: SRAM Apex · Crankset: SRAM X1 32t / S-M 170mm / L-XL 175mm · Bottom bracket: SRAM DUB BSA 73 · Cassette: SRAM GX 10-52t 12spd · Chain: SRAM NX
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: SRAM G2 4P; Front Brake Rotor: SRAM HS2 180mm 6B; Rear Brake Rotor: SRAM HS2 180mm 6B; Brake Levers: SRAM Apex
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29" · Rims: RaceFace ARC 27 Offset · Hubs: (F) Formula 15x110mm / (R) Formula 12x148mm XD · Front tire: Maxxis Dissector 29x2.4" · Rear tire: Maxxis Forekaster 29x2.4"
Controls and contact points
Archived: Headset: FSA No.9M ZS44/EC44 · Handlebar: Ritchey Beacon Comp / S 46cm / M 50cm / L-XL 52cm · Stem: Ritchey Comp Trail / S 35mm / M 45mm / L-XL 60mm · Seatpost: TranzX Dropper +RAD Internal 31.6mm / S 125mm / M 150mm / L-XL 170mm · Saddle: WTB Volt
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
