Lowest0.75:1
Highest3.27:1
Total range436%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.35; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Kona Stuff
Original specifications: Shimano Deore · 8-speed rear derailleur · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #20359- Model year
- 2010
- Category
- Mountain
- Original MSRP
- $999.00
- Sizes
- 13", 14", 16", 17"
- Colors
- Black
- In this record
- 26 specifications · archived image · original MSRP
Model history 10 other years
Browse other years
Compare side by side
Identification clues
2010 archived details
- Published colors
- Black
- Frame
- Kona Clump 7005 Aluminum
- Original equipment
- Dirt Jump Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildKona Clump 7005 Aluminum · Dirt Jump Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Kona Clump 7005 Aluminum |
| Fork | Marzocchi Dirt Jumper 2 w/20mm axle, 100mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | Dirt Jump Mix |
|---|---|
| Shifters | Shimano Acera |
| Front Derailleur | Shimano Alivio |
| Rear Derailleur | Shimano Deore |
| Crankset | FSA Step Up w/bashguard, 36/24 teeth |
| Bottom Bracket | RPM Isis DH |
| Cassette | Shimano HG30 |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC HG40 |
| Pedals | Kona Jackshit |
Brakes
| Brakes | Tektro auriga Comp Hydraulic Disc w/6" rotor brakes, Tektro Auriga Comp hydraulic levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless FSA internal ZST-10 |
|---|---|
| Handlebar | Kona OB/DH |
| Handlebar Extensions | Not included |
| Stem | Kona OB/DH |
| Saddle | Kona DJ |
| Seatpost | Kona Thumb |
Wheels & Tires
| Hubs | Front: Formula disc, Rear: Shimano M475 disc |
|---|---|
| Rims | Alex DM-24 |
| Spokes | Stainless, 14ga. (2.0mm) |
| Front Tire | 26 x 2.35 Kenda Nevegal |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
KMC HG40
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Shimano HG30
More parts (6)Fewer parts
FSA Step Up w/bashguard
36/24 teeth
Shimano Alivio
Shimano Deore
Shimano Acera
1 1/8" threadless FSA internal ZST-10
Alex DM-24
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.35 Kenda Nevegal
- Drivetrain
- 8-speed
- Bottom bracket / shell
- RPM ISIS DH
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Marzocchi Dirt Jumper 2 w/20mm axle, 100mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: Marzocchi Dirt Jumper 2 w/20mm axle, 100mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Dirt Jump Mix · Shifters: Shimano Acera · Front derailleur: Shimano Alivio · Rear derailleur: Shimano Deore · Crankset: FSA Step Up w/bashguard, 36/24 teeth · Bottom bracket: RPM ISIS DH · Cassette: Shimano HG30 · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC HG40
Brakes
Inspect the brakes →Archived: Brakes: Tektro auriga Comp Hydraulic Disc w/6" rotor brakes, Tektro Auriga Comp hydraulic levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Alex DM-24 · Hubs: Front: Formula disc, Rear: Shimano M475 disc · Front tire: 26 x 2.35 Kenda Nevegal
Controls and contact points
Archived: Headset: 1 1/8" threadless FSA internal ZST-10 · Handlebar: Kona OB/DH · Stem: Kona OB/DH · Seatpost: Kona Thumb · Saddle: Kona DJ · Pedals: Kona Jackshit
