Mountain bike, front & rear suspension
Velopedia Bicycle Archive
2003 Kona Stuff
Mountain bike, front suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $799.00
- Sizes
- 14", 15", 15.5", 17", 17.5"
- Colors
- Flat Green
- Archive ID
- 38708
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 aluminum |
| Fork | Marzocchi EXR, 100mm travel |
| Fork Material | Aluminum/magnesium, single crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Alivio |
| Front Derailleur | Shimano Alivio |
| Rear Derailleur | Shimano Alivio |
| Crankset | TruVativ Hussefelt, 22/32 teeth |
| Bottom Bracket | TruVativ ISIS Drive Hussefelt |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | Shimano CN-IG31, 1/2 x 3/32" |
| Pedals | Kona JackShit |
Brakes
| Brakes | Shimano BR-M475 Mechanical Disc brakes, Avid AD3 Levers levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Aheadset SX-1 |
|---|---|
| Handlebar | Kona DH Aluminum |
| Handlebar Extensions | Not included |
| Stem | Kona Clump |
| Saddle | SDG Gordo |
| Seatpost | Kona Thumb |
Wheels & Tires
| Hubs | Front: Shimano HB-M475, Rear: Shimano FH-M475 |
|---|---|
| Rims | Sun Rims Ditch Witch |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Front Tire | 26 x 2.10" Tioga Factory DH |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
