2005 Jamis Aragon
Hybrid bicycle from the Velopedia specification archive.
- Original MSRP
- $379.95
- Sizes
- 14.5", 16.5", 18.5", 20.5", 22", womens 14.5", womens 17.5"
- Colors
- Silver/Blue, Nickel/Silver, Silver/Rose
- Weight
- 31.5
- Archive ID
- 93147
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | SR Suntour CR880, 75mm travel |
| Fork Material | Aluminum/magnesium, single crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Hybrid Mix |
|---|---|
| Shifters | Shimano Acera EF29 |
| Front Derailleur | Shimano Tourney TY-32, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Acera |
| Crankset | Shimano FC-203, 28/38/48 teeth |
| Bottom Bracket | Sealed, 117.5mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC IG-51, 1/2 x 3/32" |
| Pedals | Platform, resin |
Brakes
| Brakes | Tektro linear-pull brakes, Shimano Acera levers |
|---|
Cockpit & Contact Points
| Headset | 1" threaded steel |
|---|---|
| Handlebar | Steel, 1" rise |
| Handlebar Extensions | Not included |
| Stem | Aluminum, adjustable |
| Saddle | Jamis Comfort |
| Seatpost | Aluminum suspension, 27.2mm diameter |
Wheels & Tires
| Hubs | Formula aluminum, Q/R |
|---|---|
| Rims | Weinmann Zac 19, 36-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 38c Cheng Shin C-1069 |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
