2026 Giant Contend SL 0

Original manufacturer specifications including geometry for 6 published sizes.

Share owner experience

Selling this bike? Create a shareable bike record

What Velopedia knows

Model year
2026
Category
Road
Original MSRP
$2,300.00
Sizes
XS, S, M, M/L, L
Colors
Pearl White/Charcoal
Geometry
6 manufacturer sizes · Geometry context
Record coverage
19 preserved details · 8 archived images · original MSRP · preserved geometry
Archive ID
900001210
Campaign

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XSSMM/LL

Published colors

Pearl White/Charcoal

Frameset

Frame ConstructionALUXX-SL Grade Aluminum 12x142mm Thru-axle, Disc
Frame MaterialAluminum
ForkAdvanced-Grade Composite, Full Carbon, OverDrive Steerer, 12x100mm thru-axle, Disc
Fork MaterialCarbon Fiber

Drivetrain

ShiftersShimano 105
Front DerailleurShimano 105
Rear DerailleurShimano 105
CranksetShimano 105, 50/34T
Bottom BracketShimano, PressFit RS500
CassetteShimano 105, 11X36T
ChainKMC X12L-1

Brakes

BrakesShimano 105 Hydraulic Disc Brake [F]160mm [R]140mm

Cockpit & Contact Points

HandlebarGiant Contact (w/Flare) Drop: 125mm / Reach: 72m
StemGiant Contact Aerolight
SaddleGiant Grit Core
SeatpostAL D-fuse SP-2056, 350mm

Wheels & Tires

RimsGiant ALP Disc 12mm Thru-Axle
Front TireGiant SR 1 700X28C, 60 TPI
Rear TireGiant SR 1 700X28C, 60 TPI

Size-specific frame data

Geometry

6 sizes · 17 measurements

Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.

MeasurementXSSMMLLXL
Seat tube410 mm445 mm480 mm515 mm535 mm565 mm
Top tube515 mm530 mm545 mm560 mm575 mm590 mm
Head tube125 mm135 mm150 mm175 mm195 mm215 mm
Head-tube angle70.5°71.8°72.5°72.5°72.5°72.5°
Seat-tube angle74.5°74°73.5°73°73°73°
Chainstay / rear center420 mm420 mm420 mm420 mm420 mm420 mm
Wheelbase995.2 mm994.4 mm997.7 mm1010 mm1025.2 mm1040.4 mm
Bottom-bracket drop75 mm75 mm75 mm70 mm70 mm70 mm
Reach368.9 mm374.9 mm379.8 mm383.7 mm392.9 mm402 mm
Stack526.8 mm540.8 mm557.8 mm576.6 mm595.7 mm614.8 mm
Standover height689.3 mm716.3 mm744 mm777.5 mm796 mm822 mm
Fork offset / rake50 mm50 mm50 mm50 mm50 mm50 mm
Trail71.1 mm62.9 mm58.1 mm58.1 mm58.1 mm58.1 mm
Crank length170 mm170 mm172.5 mm175 mm175 mm175 mm
Stem length80 mm90 mm100 mm100 mm110 mm110 mm
Handlebar width400 mm400 mm420 mm420 mm440 mm420 mm
Wheel size700C700C700C700C700C700C

Geometry source: Giant first-party size geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.

Geometry tools

Analyze a published size

Choose a size

XS geometry

Archive context: The head angle of 70.5° sits toward the slacker end. Its bottom-bracket drop of 75 mm sits toward the deeper-drop end. Its trail of 71.1 mm sits toward the higher-trail end.

Compared with 64 distinct road geometries in the XS-equivalent size cohort from model years 2024–2027 in the Velopedia archive.
Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry

Parts & serviceability

Find replacement parts

2 top part searches
Bottom bracketQualified part search
Shimano, PressFit RS500 Named archived component — verify dimensions
CranksetQualified part search
Shimano 105, 50/34T Component family — verify exact version

Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Commercial relationships do not influence Archive specifications or analysis.

Campaign

Used-bike inspection

If you’re buying this bike used

Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.

Follow the full used-bike inspection order →
  • FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
  • BrakesBoth levers should feel firm and return cleanly. Check for fluid around the levers and calipers, inspect pad thickness and contamination, and look for worn or bent rotors.Inspect the brakes →
  • DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
  • Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
  • Bottom bracketTurn the cranks slowly, feel for rough bearings and check for side-to-side play. Creaking under load deserves investigation but does not identify the source by itself.Inspect the bottom bracket and shell →
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
0 of 19 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2026 Giant Contend SL 0 · Road · Published sizes: XS, S, M, M/L, L

Archived: Frame: ALUXX-SL Grade Aluminum 12x142mm Thru-axle, Disc · Fork: Advanced-Grade Composite, Full Carbon, OverDrive Steerer, 12x100mm thru-axle, Disc · Carbon Fiber

Archived: Shifters: Shimano 105 · Front derailleur: Shimano 105 · Rear derailleur: Shimano 105 · Crankset: Shimano 105, 50/34T · Bottom bracket: Shimano, PressFit RS500 · Cassette: Shimano 105, 11X36T · Chain: KMC X12L-1

Archived: Brakes: Shimano 105 Hydraulic Disc Brake [F]160mm [R]140mm

Archived: Rims: Giant ALP Disc 12mm Thru-Axle · Front tire: Giant SR 1 700X28C, 60 TPI · Rear tire: Giant SR 1 700X28C, 60 TPI

Controls and contact points

Archived: Handlebar: Giant Contact (w/Flare) Drop: 125mm / Reach: 72m · Stem: Giant Contact Aerolight · Seatpost: AL D-fuse SP-2056, 350mm · Saddle: Giant Grit Core

Before and during the test ride

Follow the full used-bike inspection order →

Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
