2020 Giant TCX Advanced Pro 1

Original specifications: geometry for 5 published sizes.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #900002224
Model year
2020
Category
Gravel & Cyclocross
Original MSRP
$4,400.00
Sizes
S, M, ML, L, XL
Colors
Metallic Black
Geometry
5 manufacturer sizes
In this record
20 specifications · archived image · original MSRP · geometry
Model history 5 other years

Browse other years

Compare side by side

Identification clues

2020 archived details

Published colors
Metallic Black
Frame
Carbon Fiber

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMMLLXL

Published colors

Metallic Black

Frameset

Frame ConstructionAdvanced-Grade Composite, 12mm thru-axle, disc
Frame MaterialCarbon Fiber
ForkAdvanced-Grade Composite, full-composite OverDrive 2 steerer, disc
Fork MaterialCarbon Fiber

Drivetrain

ShiftersSRAM Force CX1
Rear DerailleurSRAM Force CX1
CranksetSRAM Force CX 1, 40t
Bottom BracketSRAM GXP, press fit
CassetteSRAM PG1170, 11x36
ChainSRAM PC1170

Brakes

BrakesSRAM Force CX1 hydraulic

Cockpit & Contact Points

HandlebarGiant Contact SL
StemGiant Contact SL
SaddleGiant Contact SL (neutral)
SeatpostGiant D-Fuse SL, composite

Wheels & Tires

HubsGiant CXR-1 WheelSystem
RimsGiant CXR-1 Composite WheelSystem
SpokesGiant CXR-1 WheelSystem
Front TireMaxxis All-Terrene, 700x33, tubeless
Rear TireMaxxis All-Terrene, 700x33, tubeless

Geometry

5 sizes · 17 measurements

Frame measurements by size.

All geometry measurements5 sizes · 17 measurements
MeasurementSMMLLXL
Seat tube500 mm525 mm545 mm555 mm565 mm
Top tube530 mm545 mm560 mm575 mm590 mm
Head tube130 mm145 mm160 mm175 mm190 mm
Head-tube angle71°71.5°72°72.5°72.5°
Seat-tube angle73.5°73°73°73°73°
Chainstay / rear center430 mm430 mm430 mm430 mm430 mm
Wheelbase1014 mm1019 mm1030 mm1040 mm1055 mm
Bottom-bracket drop60 mm60 mm60 mm60 mm60 mm
Reach370 mm375 mm385 mm395 mm406 mm
Stack540 mm556 mm572 mm589 mm603 mm
Standover height783 mm803 mm821 mm832 mm843 mm
Fork offset / rake50 mm50 mm50 mm50 mm50 mm
Trail68 mm65 mm62 mm59 mm59 mm
Crank length170 mm172.5 mm172.5 mm175 mm175 mm
Stem length90 mm110 mm110 mm110 mm120 mm
Handlebar width400 mm420 mm420 mm440 mm440 mm
Wheel size700C700C700C700C700C

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes40T · 11–36T
Lowest1.11:1 Highest3.64:1 Total range327%
Estimated speed At 90 RPM Lowest gear8.1 mph Highest gear26.4 mph

Rear tire: 700C×33.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Cassette · Original
SRAM PG1170

11x36

Retailer offers
Front tire · Original
Maxxis All-Terrene

700x33, tubeless

Retailer offers
Crankset · Original
SRAM Force CX 1, 40t
170 mm Frame sizes S
172.5 mm Frame sizes M / ML
175 mm Frame sizes L / XL
Retailer offers

SRAM Force D2 1 DUB 12-Speed Direct Mount Crankset Iridescent, 175mm, 40T, Wide

175mm, 40T, Wide · Frame sizes L / XL

Model match

More parts (2)Fewer parts
Chain · Original
SRAM PC1170
Bottom bracket · Original
SRAM GXP

press fit

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Maxxis All-Terrene, 700x33, tubeless
Rear tire
Maxxis All-Terrene, 700x33, tubeless
Bottom bracket / shell
SRAM GXP, press fit
Equipment inspection checks 11 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: Advanced-Grade Composite, 12mm thru-axle, disc · Fork: Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc · Carbon Fiber

Archived: Shifters: SRAM Force CX1 · Rear derailleur: SRAM Force CX1 · Crankset: SRAM Force CX 1, 40t · Bottom bracket: SRAM GXP, press fit · Cassette: SRAM PG1170, 11x36 · Chain: SRAM PC1170

Archived: Brakes: SRAM Force CX1 hydraulic

Archived: Rims: Giant CXR-1 Composite WheelSystem · Hubs: Giant CXR-1 WheelSystem · Front tire: Maxxis All-Terrene, 700x33, tubeless · Rear tire: Maxxis All-Terrene, 700x33, tubeless

Controls and contact points

Archived: Handlebar: Giant Contact SL · Stem: Giant Contact SL · Seatpost: Giant D-Fuse SL, composite · Saddle: Giant Contact SL (neutral)
