Lowest1.25:1
Highest4.33:1
Total range347%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×25; rear size isn’t listed.
Velopedia Bicycle Archive
2006 Fuji Newest 3.0
Original specifications: Shimano Sora · 8-speed · mechanical rear derailleur · 700c wheels · 24.4 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #94390- Model year
- 2006
- Category
- Road
- Original MSRP
- $620.00
- Sizes
- 42cm, 46cm, 50cm, 54cm, 58cm
- Colors
- Fuji Red/White
- Weight
- 24.4 lb
- In this record
- 24 specifications · archived image · original MSRP
Model history 3 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Fuji Red/White
- Frame
- Fuji Altair 1
- Original equipment
- Road Mix Triple
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildFuji Altair 1 · Road Mix Triple · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Fuji Altair 1 |
| Fork | Fuji Aero |
| Fork Material | Aluminum, aero crown |
Drivetrain
| Component Group | Road Mix Triple |
|---|---|
| Shifters | Shimano Sora STI Dual Control |
| Front Derailleur | Shimano Sora Triple, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Sora GS |
| Crankset | Fuji Forged AL Road, 30/42/52 teeth |
| Bottom Bracket | Fuji Sealed Square Taper |
| Rear Cogs | 8-speed, 12 - 24 teeth |
| Chain | Shimano CN-HG50, 1/2 x 3/32" |
| Pedals | Wellgo road w/clips and straps |
Brakes
| Brakes | ProMax Forged Road brakes, Shimano Sora STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated sealed |
|---|---|
| Handlebar | Fuji Aluminum Road |
| Stem | Fuji Adjustable Road |
| Saddle | Fuji Road Sport |
| Seatpost | Fuji Superlite Micro-Adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Formula aluminum, Q/R |
|---|---|
| Rims | Alex R-500, 32-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Front Tire | 700 x 25c Kenda |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano CN-HG50
1/2 x 3/32"
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Shimano CN-HG50 on eBaySponsored links
Fuji Superlite Micro-Adjust
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
700 x 25c Kenda
Replacement search: 700cx25 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (4)Fewer parts
Wellgo road w/clips and straps
Shimano Sora GS
Shimano Sora STI Dual Control
Alex R-500
32-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 25c Kenda
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Fuji Sealed Square Taper
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji Aero · Aluminum, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Road Mix Triple · Shifters: Shimano Sora STI Dual Control · Front derailleur: Shimano Sora Triple, bottom-pull/clamp-on 31.8mm · Rear derailleur: Shimano Sora GS · Crankset: Fuji Forged AL Road, 30/42/52 teeth · Bottom bracket: Fuji Sealed Square Taper · Rear cogs: 8-speed, 12 - 24 teeth · Chain: Shimano CN-HG50, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: ProMax Forged Road brakes, Shimano Sora STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex R-500, 32-hole · Hubs: Formula aluminum, Q/R · Front tire: 700 x 25c Kenda
Controls and contact points
Archived: Headset: 1 1/8" integrated sealed · Handlebar: Fuji Aluminum Road · Stem: Fuji Adjustable Road · Seatpost: Fuji Superlite Micro-Adjust, 27.2mm diameter · Saddle: Fuji Road Sport · Pedals: Wellgo road w/clips and straps
