Lowest1.70:1
Highest4.42:1
Total range260%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×23; rear size isn’t listed.
Velopedia Bicycle Archive
2006 Fuji Aloha 1.0
Original specifications: Shimano Ultegra · 10-speed · mechanical rear derailleur · 700c wheels · 18.7 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #94420- Model year
- 2006
- Category
- Road
- Original MSRP
- $1,800.00
- Sizes
- 49cm, 52cm, 54cm, 56cm, 58cm, 61cm
- Colors
- Gloss Black/White
- Weight
- 18.7 lb
- In this record
- 24 specifications · archived image · original MSRP
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Gloss Black/White
- Frame
- A-6 Quaternary aluminum
- Original equipment
- Road Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildA-6 Quaternary aluminum · Road Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | A-6 Quaternary aluminum |
| Fork | Fuji FC-770 Carbon |
| Fork Material | Carbon fiber/aluminum steerer, aero crown |
Drivetrain
| Component Group | Road Mix |
|---|---|
| Shifters | Shimano Dura-Ace bar-end |
| Front Derailleur | Shimano Ultegra, braze-on |
| Rear Derailleur | Shimano Ultegra |
| Crankset | Truvativ Rouleur GXP, 39/53 teeth |
| Bottom Bracket | Truvativ GXP |
| Rear Cogs | 10-speed, 12 - 23 teeth |
| Chain | Shimano Ultegra, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Tektro RX40 brakes, Tektro RX 4.0 front/Tektro RX4.0 rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated VP |
|---|---|
| Handlebar | Ritchey Pro Crowbar |
| Handlebar Extensions | Ritchey Pro Clip-On |
| Stem | Ritchey Logic Pro |
| Saddle | Fuji Custom TRI Cr-Mo |
| Seatpost | Ritchey Pro, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Formula XR1 Aero, Rear: Formula XR-1 Aero |
|---|---|
| Rims | Formula XR-1 Aero |
| Front Tire | 700 x 23c Continental Ultra Sport |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano Ultegra
1/2 x 3/32"
Retailer offers
Shimano Ultegra CN-6701 Chain 10 Speed, 116 Link
Specification match
700 x 23c Continental Ultra Sport
Retailer offers
Continental Ultra Sport III Clincher Tire Black, Pure Grip, 700x23mm
700x23c
Model match
Continental Sport on eBaySponsored links
Ritchey Pro
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (6)Fewer parts
Shimano Ultegra
braze-on
Shimano Ultegra
Shimano Dura-Ace bar-end
Ritchey Pro Crowbar
Ritchey Logic Pro
Formula XR-1 Aero
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23c Continental Ultra Sport
- Drivetrain
- 10-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Truvativ GXP
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji FC-770 Carbon · Carbon fiber/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Road Mix · Shifters: Shimano Dura-Ace bar-end · Front derailleur: Shimano Ultegra, braze-on · Rear derailleur: Shimano Ultegra · Crankset: Truvativ Rouleur GXP, 39/53 teeth · Bottom bracket: Truvativ GXP · Rear cogs: 10-speed, 12 - 23 teeth · Chain: Shimano Ultegra, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro RX40 brakes, Tektro RX 4.0 front/Tektro RX4.0 rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Formula XR-1 Aero · Hubs: Front: Formula XR1 Aero, Rear: Formula XR-1 Aero · Front tire: 700 x 23c Continental Ultra Sport
Controls and contact points
Archived: Headset: 1 1/8" integrated VP · Handlebar: Ritchey Pro Crowbar · Stem: Ritchey Logic Pro · Seatpost: Ritchey Pro, 27.2mm diameter · Saddle: Fuji Custom TRI Cr-Mo · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
