Velopedia Bicycle Archive

2014 Felt Brougham

Original specifications: 700c wheels · 22.75 lbs published weight.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #1436510
Model year
2014
Category
Track
Original MSRP
$549.00
Sizes
51cm, 54cm, 56cm, 58cm, 61cm
Colors
Ivy Green, Stealth Black
Weight
22.75 lbs
In this record
18 specifications · 2 archived images · original MSRP
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2014 archived details

Published colors
Ivy Green, Stealth Black
Frame
Felt single speed custom butted 4130 TIG-welded Cr-Mo tubes

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildFelt single speed custom butted 4130 TIG-welded Cr-Mo tubes · 700c

Manufacturer catalog

Published sizes and colors

5 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

51cm54cm56cm58cm61cm

Published colors

Ivy GreenStealth Black

Frameset

Frame Constructionbutted tapered seatstays w/ horizontal machined Cr-Mo dropouts, horizontal top tube
Frame MaterialFelt single speed custom butted 4130 TIG-welded Cr-Mo tubes
ForkFelt Urban design, 100% Cr-Mo, 1.125" threadless steerer & oversized straight fork blades, 43mm offset

Drivetrain

CranksetForged aluminum, 47T x 3/32", aluminum
Bottom BracketEuro sealed bearing, 68mm
Rear CogsFreewheel 17T x 3/32" Fixed cog 17T x 3/32" w/ lock ring
ChainKMC Z610H 3/32"

Brakes

BrakesTektro dual pivot caliper front & rear, stainless hardware

Cockpit & Contact Points

HeadsetFSA 1.125" threadless, aluminum spacer, Felt Tornado aluminum top cap
StemFelt aluminum forged, 4-bolt clamp
SaddleFelt Urban classic road saddle w/ riveted custom cover & steel rails
SeatpostAluminum micro-adjust, 27.2 x 300mm

Wheels & Tires

HubsAluminum hi-flange, track nuts, 32H, w/ front hub shiner, Aluminum, flip-flop threaded fixed / freewheel, hi-flange, track nuts, 32H
RimsAlex DA30 double wall aluminum, 30mm deep V-section aero rim
Spokes14G stainless steel
Front TireVittoria Randonneur, 700 x 28c
Rear TireVittoria Randonneur, 700 x 28c
Wheel Size700c

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
Vittoria Randonneur

700 x 28c

Retailer offers
Seatpost · Original
Aluminum micro-adjust

27.2 x 300mm

Retailer offers
Headset · Original
FSA 1.125" threadless

aluminum spacer, Felt Tornado aluminum top cap

More parts (1)Fewer parts
Rims · Original
Alex DA30 double wall aluminum

30mm deep V-section aero rim

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Vittoria Randonneur, 700 x 28c
Rear tire
Vittoria Randonneur, 700 x 28c
Seatpost diameter
27.2 mm
Bottom bracket / shell
Euro sealed bearing, 68mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: butted tapered seatstays w/ horizontal machined Cr-Mo dropouts, horizontal top tube · Fork: Felt Urban design, 100% Cr-Mo, 1.125" threadless steerer & oversized straight fork blades, 43mm offset

Archived: Crankset: Forged aluminum, 47T x 3/32", aluminum · Bottom bracket: Euro sealed bearing, 68mm · Rear cogs: Freewheel 17T x 3/32" Fixed cog 17T x 3/32" w/ lock ring · Chain: KMC Z610H 3/32"

Archived: Brakes: Tektro dual pivot caliper front & rear, stainless hardware

Archived: Wheel size: 700c · Rims: Alex DA30 double wall aluminum, 30mm deep V-section aero rim · Hubs: Aluminum hi-flange, track nuts, 32H, w/ front hub shiner, Aluminum, flip-flop threaded fixed / freewheel, hi-flange, track nuts, 32H · Front tire: Vittoria Randonneur, 700 x 28c · Rear tire: Vittoria Randonneur, 700 x 28c

Controls and contact points

Archived: Headset: FSA 1.125" threadless, aluminum spacer, Felt Tornado aluminum top cap · Stem: Felt aluminum forged, 4-bolt clamp · Seatpost: Aluminum micro-adjust, 27.2 x 300mm · Saddle: Felt Urban classic road saddle w/ riveted custom cover & steel rails

My Garage

Velopedia

Enter your email and Velopedia will send a private sign-in link. No password required.

Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.

This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.

Add fit, maintenance and buyer detailsOptional · five additional fields

Your contribution goes directly to Velopedia’s private review queue. We’ll email an optional confirmation link plus a private edit and withdrawal link, but you do not need to confirm your email before an administrator can review or approve the submission.

Already contributed? Send me a fresh private edit link

For privacy, Velopedia shows the same confirmation whether or not an experience exists.

Gallery2 images

No recent price sample is available for this bike. Check eBay for matching listings.

Find this bike on eBay

Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.

Campaign

Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
