Velopedia Bicycle Archive

2011 Felt Brougham

Original specifications: Track Mix drivetrain · 700c wheels · 22.70 lbs published weight.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #23077
Model year
2011
Category
Track
Original MSRP
$529.00
Sizes
51, 54, 56, 58, 61cm
Colors
Gloss raw clear, Gloss Black, AAA chrome
Weight
22.70 lbs
In this record
26 specifications · original MSRP
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2011 archived details

Published colors
Gloss raw clear, Gloss Black, AAA chrome
Frame
4130 butted chromoly
Original equipment
Track Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build4130 butted chromoly · Track Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

15 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

5154565861cm

Published colors

Gloss Raw ClearGloss BlackAAA chrome
View 15 archived size/color combinations
SizeColor
51Gloss Raw Clear
54Gloss Raw Clear
56Gloss Raw Clear
58Gloss Raw Clear
61cmGloss Raw Clear
51Gloss Black
54Gloss Black
56Gloss Black
58Gloss Black
61cmGloss Black
51AAA chrome
54AAA chrome
56AAA chrome
58AAA chrome
61cmAAA chrome

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material4130 butted chromoly
ForkFelt Urban Cr-Mo
Fork MaterialCro-Moly

Drivetrain

Component GroupTrack Mix
CranksetTrack Cold Forged Aluminum, 47t teeth
Bottom BracketSquare Taper
BB Shell Width68mm
CassetteFreewheel
Rear Cogs1-speed, 17 teeth
ChainKMC Z610X, 1/2 x 3/32"
PedalsFelt BMX FB

Brakes

BrakesTektro dual pivot brakes, Tektro levers

Cockpit & Contact Points

Headset1 1/8" FSA
HandlebarFelt Designed 6061 Urban Riser Bar, 25.4mm, 540cm
Handlebar ExtensionsNot included
StemFelt AL 6061
SaddleFELT Urban Classic Road
SeatpostFelt SL 6061 Aluminum

Wheels & Tires

HubsFront: Felt TkR-4 hi-flange, Rear: Felt TkR-4 Double-Threaded Fixed/Fixed Hi-Flange
RimsFelt ALU Deep-V Aero 30mm, 28-hole
SpokesStainless Steel stainless
Spoke NipplesBrass
Front Tire700 x 23c Vittoria Zaffiro
Rear Tire700 x 28c Vittoria Randonneur
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes47T · 17T · 1-speed
Ratio2.76:1
Estimated speed At 90 RPM Gear19.8 mph

Rear tire: 700C×28.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
700 x 23c Vittoria Zaffiro
Retailer offers
Rear tire · Original
700 x 28c Vittoria Randonneur

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Front: 700 x 23c Vittoria Zaffiro, Rear: 700 x 28c Vittoria Randonneur
Drivetrain
1-speed
Bottom bracket / shell
Square Taper · 68mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Felt Urban Cr-Mo · Cro-Moly

Archived: Group: Track Mix · Crankset: Track Cold Forged Aluminum, 47t teeth · Bottom bracket: Square Taper · Cassette: Freewheel · Rear cogs: 1-speed, 17 teeth · Chain: KMC Z610X, 1/2 x 3/32"

Archived: Brakes: Tektro dual pivot brakes, Tektro levers

Archived: Wheel size: 700c wheels · Rims: Felt ALU Deep-V Aero 30mm, 28-hole · Hubs: Front: Felt TkR-4 hi-flange, Rear: Felt TkR-4 Double-Threaded Fixed/Fixed Hi-Flange · Front tire: Front: 700 x 23c Vittoria Zaffiro, Rear: 700 x 28c Vittoria Randonneur

Controls and contact points

Archived: Headset: 1 1/8" FSA · Handlebar: Felt Designed 6061 Urban Riser Bar, 25.4mm, 540cm · Stem: Felt AL 6061 · Seatpost: Felt SL 6061 Aluminum · Saddle: FELT Urban Classic Road · Pedals: Felt BMX FB
