Original specifications: geometry for 4 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900001427Browse other years
Compare side by side
2027 archived details
Clues, not proof of model year. Colors vary and components may have been replaced.
| Frame Construction | ABSOLUT Al V4; ALLOY 6061, Triple Butted (T4, T6) |
|---|---|
| Frame Material | Aluminum |
| Fork | MARZOCCHI Bomber DJ, 100 mm; 15 x 100 mm, 37 mm offset |
| Crankset | PROWHEEL 165 mm, steel Narrow wide, crank alloy black; Chainring : 30t, alloy 6061 |
|---|---|
| Bottom Bracket | Threaded Euro BB; Alloy cups, 4 sealed bearings |
| Chain | KMC Z1-Bubu; 1/2'' X 1/8'' |
| Pedals | No |
| Brakes | SRAM DB8, 4-pistons, hydraulic disc brake; Rotors : SRAM Centerline 160 mm, 6-bolt |
|---|
| Headset | ACROS ZS44/ZS56; Alloy cups, sealed bearings |
|---|---|
| Handlebar | BURGTEC Ride High; 35 mm, 800 mm width, 38 mm rise, Alloy 6061 |
| Stem | BURGTEC MK3; 35 mm extension, 35 mm |
| Saddle | COMMENCAL; Soft padding, steel rails |
| Seatpost | RIDE ALPHA; 31.6 mm, 250 mm length |
| Hubs | DT SWISS 370 LN; Rear : 32h, sealed bearings, 10 x 135 mm, Hyperglide - Front : 32h, sealed bearings, 15 x 100 mm |
|---|---|
| Rims | DT SWISS D1900; 26'', 32h, 30 mm inner width |
| Front Tire | MAXXIS DTH; 26"x2.3", Clincher |
| Rear Tire | MAXXIS DTH; 26"x2.3", Clincher |
No specifications match. Try a component name or clear your search.
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
| Measurement | 24 | S | M | L |
|---|---|---|---|---|
| Seat tube | 270 mm | 310 mm | 310 mm | 310 mm |
| Effective top tube | 516 mm | 577 mm | 597 mm | 622 mm |
| Head tube | 115 mm | 120 mm | 120 mm | 120 mm |
| Head-tube angle | 69° | 69° | 69° | 69° |
| Seat-tube angle | 72.5° | 72° | 72° | 72° |
| Chainstay / rear center | 365 mm | 390 mm | 390 mm | 390 mm |
| Wheelbase | 972 mm | 1037 mm | 1057 mm | 1082 mm |
| Bottom-bracket drop | 8 mm | 25 mm | 25 mm | 25 mm |
| Reach | 360 mm | 395 mm | 415 mm | 440 mm |
| Stack | 527 mm | 566 mm | 566 mm | 566 mm |
| Fork length / axle-to-crown | 460 mm | 470 mm | 470 mm | 470 mm |
Dimensions as recorded.
Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.
Your changes apply to this calculation. The archived build stays unchanged.
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
26"x2.3", Clincher

Model match
31.6 mm, 250 mm length

Replacement option
26'', 32h, 30 mm inner width
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Archived specifications for reference. Check the fitted parts before ordering.
Not confirmed in this record: Drivetrain. Check the fitted parts for these details.
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Archived: 2027 Commencal Absolut Bomber · Mountain · Published sizes: 24, S, M, L
Archived: Frame: ABSOLUT Al V4; ALLOY 6061, Triple Butted (T4, T6) · Fork: MARZOCCHI Bomber DJ, 100 mm; 15 x 100 mm, 37 mm offset
Archived: Fork: MARZOCCHI Bomber DJ, 100 mm; 15 x 100 mm, 37 mm offset
Archived: Crankset: PROWHEEL 165 mm, steel Narrow wide, crank alloy black; Chainring : 30t, alloy 6061 · Bottom bracket: Threaded Euro BB; Alloy cups, 4 sealed bearings · Chain: KMC Z1-BUBU; 1/2'' x 1/8''
Archived: Brakes: SRAM DB8, 4-pistons, hydraulic disc brake; Rotors : SRAM Centerline 160 mm, 6-bolt
Archived: Rims: DT SWISS D1900; 26'', 32h, 30 mm inner width · Hubs: DT SWISS 370 LN; Rear : 32h, sealed bearings, 10 x 135 mm, Hyperglide - Front : 32h, sealed bearings, 15 x 100 mm · Front tire: MAXXIS DTH; 26"x2.3", Clincher · Rear tire: MAXXIS DTH; 26"x2.3", Clincher
Archived: Headset: ACROS ZS44/ZS56; Alloy cups, sealed bearings · Handlebar: BURGTEC Ride High; 35 mm, 800 mm width, 38 mm rise, Alloy 6061 · Stem: BURGTEC MK3; 35 mm extension, 35 mm · Seatpost: RIDE ALPHA; 31.6 mm, 250 mm length · Saddle: COMMENCAL; Soft padding, steel rails · Pedals: No
