Velopedia Bicycle Archive
2027 Canyon Neuron 5
Original manufacturer specifications including 29; 27.5 wheels, 33.52 lb published weight, geometry for 5 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2027
- Category
- Mountain
- Original MSRP
- $2,499.00
- Sizes
- XS, S, M, L, XL
- Colors
- Doppio, Aloe
- Weight
- 33.52 lb
- Geometry
- 5 manufacturer sizes · Geometry context
- Record coverage
- 20 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001576
Frameset
| Frame Construction | Canyon Neuron |
|---|---|
| Frame Material | Aluminium (AL) |
| Fork | RockShox Recon Silver RL |
| Rear Shock | RockShox Deluxe Select+ |
Drivetrain
| Shifters | Shimano M6200 |
|---|---|
| Rear Derailleur | Shimano Deore |
| Crankset | Shimano FC-M6200 |
| Bottom Bracket | BSA 73 |
| Cassette | Shimano M6200 |
| Chain | Shimano Deore M6100 |
Brakes
| Brakes | Shimano M6220 |
|---|
Cockpit & Contact Points
| Handlebar | Canyon HB0073 |
|---|---|
| Stem | Canyon ST0039 |
| Saddle | Ergon SPS20 NEO |
| Seatpost | Canyon SP0081 |
Wheels & Tires
| Wheels | Canyon XC 30 AL Wheel |
|---|---|
| Front Tire | Schwalbe Wicked Will |
| Rear Tire | Schwalbe Nobby Nic |
| Wheel Size | 29; 27.5 |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XL | XS | S | M | L |
|---|---|---|---|---|---|
| Seat tube | 500 mm | 390 mm | 390 mm | 425 mm | 460 mm |
| Effective top tube | 674 mm | 556 mm | 579 mm | 611 mm | 639 mm |
| Head tube | 143 mm | 90 mm | 100 mm | 110 mm | 125 mm |
| Head-tube angle | 66° | 66° | 66° | 66° | 66° |
| Seat-tube angle | 76° | 76° | 76° | 76° | 76° |
| Chainstay / rear center | 440 mm | 430 mm | 430 mm | 440 mm | 440 mm |
| Wheelbase | 1271 mm | 1139 mm | 1164 mm | 1203 mm | 1234 mm |
| Bottom-bracket drop | 38 mm | 18 mm | 18 mm | 38 mm | 38 mm |
| Reach | 510 mm | 410 mm | 430 mm | 455 mm | 480 mm |
| Stack | 656 mm | 587 mm | 596 mm | 626 mm | 639 mm |
| Standover height | 772 mm | 756 mm | 760 mm | 760 mm | 766 mm |
| Crank length | 175 mm | 165 mm | 170 mm | 170 mm | 175 mm |
| Stem length | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheel size | 29 | 27.5 | 27.5 | 29 | 29 |
Geometry source: Canyon first-party ProductGroup geometry ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
XL geometry
Archive context: Its stack of 656 mm sits toward the taller end. Its reach of 510 mm sits somewhat longer than typical. The head angle of 66° sits somewhat steeper than typical.
Compared with 143 distinct mountain geometries in the XL-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry XS geometry
Archive context: Its bottom-bracket drop of 18 mm sits toward the shallower-drop end. Its stack of 587 mm sits somewhat lower than typical. The chainstay of 430 mm sits somewhat shorter than typical.
Compared with 55 distinct mountain geometries in the XS-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: Its bottom-bracket drop of 18 mm sits toward the shallower-drop end. Its stack of 596 mm sits somewhat lower than typical. The chainstay of 430 mm sits somewhat shorter than typical.
Compared with 168 distinct mountain geometries in the Small-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: The chainstay of 440 mm sits somewhat longer than typical. Its stack of 626 mm sits somewhat taller than typical. The head angle of 66° sits somewhat steeper than typical.
Compared with 171 distinct mountain geometries in the Medium-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: Its stack of 639 mm sits somewhat taller than typical. The chainstay of 440 mm sits somewhat longer than typical. The head angle of 66° sits somewhat steeper than typical.
Compared with 167 distinct mountain geometries in the Large-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry Parts & serviceability
Find replacement parts
Shimano Deore M6100
Exact archived model
Ergon SPS20 NEO
Named archived component — verify exact version
Shimano FC-M6200
Exact archived model
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 22 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Canyon Neuron 5 · Mountain · Published sizes: XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Canyon Neuron · Fork: RockShox Recon Silver RL
Suspension
Evaluate the suspension →Archived: Fork: RockShox Recon Silver RL · Rear shock: RockShox Deluxe Select+
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano M6200 · Rear derailleur: Shimano Deore · Crankset: Shimano FC-M6200 · Bottom bracket: BSA 73 · Cassette: Shimano M6200 · Chain: Shimano Deore M6100
Brakes
Inspect the brakes →Archived: Brakes: Shimano M6220
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29; 27.5 · Wheels: Canyon XC 30 AL Wheel · Front tire: Schwalbe Wicked Will · Rear tire: Schwalbe Nobby Nic
Controls and contact points
Archived: Handlebar: Canyon HB0073 · Stem: Canyon ST0039 · Seatpost: Canyon SP0081 · Saddle: Ergon SPS20 NEO
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
