2027 Canyon Lux Trail CF 7
Original manufacturer specifications including 29 wheels, 28.22 lb published weight, geometry for 5 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2027
- Category
- Mountain
- Original MSRP
- $4,999.00
- Sizes
- XS, S, M, L, XL
- Colors
- Grove, Glacier
- Weight
- 28.22 lb
- Geometry
- 5 manufacturer sizes · Geometry context
- Record coverage
- 20 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001591
Frameset
| Frame Construction | Canyon Lux Trail CF |
|---|---|
| Frame Material | Carbon (CF) |
| Fork | FOX 36 SL Performance Series |
| Rear Shock | FOX Float Performance |
Drivetrain
| Shifters | SRAM Eagle 90 Transmission |
|---|---|
| Rear Derailleur | SRAM Eagle 90 Transmission |
| Crankset | SRAM Eagle 90 |
| Bottom Bracket | SRAM DUB BSA |
| Cassette | SRAM XS-1275 |
| Chain | SRAM GX Eagle Transmission |
Brakes
| Brakes | SRAM Motive Bronze |
|---|
Cockpit & Contact Points
| Handlebar | Canyon HB0073 |
|---|---|
| Stem | Canyon ST0039 |
| Saddle | Ergon SPS20 NEO |
| Seatpost | Canyon SP0081 |
Wheels & Tires
| Wheels | Canyon XC 30 CF |
|---|---|
| Front Tire | Maxxis Dissector |
| Rear Tire | Maxxis Rekon |
| Wheel Size | 29 |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Seat tube | 390 mm | 400 mm | 420 mm | 450 mm | 480 mm |
| Effective top tube | 556 mm | 578 mm | 600 mm | 623 mm | 648 mm |
| Head tube | 93 mm | 93 mm | 95 mm | 108 mm | 125 mm |
| Head-tube angle | 64.8° | 64.8° | 64.8° | 64.8° | 64.8° |
| Seat-tube angle | 76.4° | 76.2° | 76.1° | 76.1° | 76° |
| Chainstay / rear center | 435 mm | 435 mm | 435 mm | 440 mm | 440 mm |
| Wheelbase | 1159 mm | 1179 mm | 1200 mm | 1231 mm | 1258 mm |
| Bottom-bracket drop | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Reach | 410 mm | 430 mm | 450 mm | 470 mm | 490 mm |
| Stack | 603 mm | 603 mm | 605 mm | 616 mm | 632 mm |
| Standover height | 809 mm | 807 mm | 808 mm | 812 mm | 817 mm |
| Crank length | 165 mm | 170 mm | 170 mm | 175 mm | 175 mm |
| Stem length | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheel size | 29 | 29 | 29 | 29 | 29 |
Geometry source: Canyon first-party ProductGroup geometry ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
XS geometry
Archive context: Its wheelbase of 1159 mm sits toward the longer end. The head angle of 64.8° sits somewhat slacker than typical. The chainstay of 435 mm sits somewhat longer than typical.
Compared with 55 distinct mountain geometries in the XS-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: Its stack of 603 mm sits somewhat lower than typical. The head angle of 64.8° sits somewhat slacker than typical. Its bottom-bracket drop of 38 mm sits close to the middle of the group.
Compared with 168 distinct mountain geometries in the Small-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: Its stack of 605 mm sits toward the lower end. Its reach of 450 mm sits close to the middle of the group. The head angle of 64.8° sits close to the middle of the group.
Compared with 171 distinct mountain geometries in the Medium-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: Its stack of 616 mm sits somewhat lower than typical. Its reach of 470 mm sits somewhat shorter than typical. The chainstay of 440 mm sits somewhat longer than typical.
Compared with 167 distinct mountain geometries in the Large-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: Its reach of 490 mm sits toward the shorter end. Its stack of 632 mm sits somewhat lower than typical. Its wheelbase of 1258 mm sits somewhat shorter than typical.
Compared with 143 distinct mountain geometries in the XL-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
SRAM GX Eagle Transmission
Interpreted as SRAM GX · 12-speed Component family — verify exact version
Maxxis Dissector
Named tire · verify the exact width
Before ordering: Confirm the exact tire width before ordering.
Maxxis Rekon
Named tire · verify the exact width
Before ordering: Confirm the exact tire width before ordering.
More qualified parts (5)
SRAM DUB BSA
Named archived component — verify dimensions
Ergon SPS20 NEO
Named archived component — verify exact version
SRAM Eagle 90
Named archived component — verify exact version
SRAM Eagle 90 Transmission
Interpreted as SRAM Eagle 90 · 12-speed Component family — verify exact version
SRAM Eagle 90 Transmission
Interpreted as SRAM Eagle 90 · 12-speed Component family — verify exact version
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 22 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Canyon Lux Trail CF 7 · Mountain · Published sizes: XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Canyon Lux Trail CF · Fork: FOX 36 SL Performance Series
Suspension
Evaluate the suspension →Archived: Fork: FOX 36 SL Performance Series · Rear shock: FOX Float Performance
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM Eagle 90 Transmission · Rear derailleur: SRAM Eagle 90 Transmission · Crankset: SRAM Eagle 90 · Bottom bracket: SRAM DUB BSA · Cassette: SRAM XS-1275 · Chain: SRAM GX Eagle Transmission
Brakes
Inspect the brakes →Archived: Brakes: SRAM Motive Bronze
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29 · Wheels: Canyon XC 30 CF · Front tire: Maxxis Dissector · Rear tire: Maxxis Rekon
Controls and contact points
Archived: Handlebar: Canyon HB0073 · Stem: Canyon ST0039 · Seatpost: Canyon SP0081 · Saddle: Ergon SPS20 NEO
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
