Velopedia Bicycle Archive
2027 Canyon Endurace CFR Di2
Original manufacturer specifications including 700C wheels, 16.71 lb published weight, geometry for 6 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2027
- Category
- Road
- Original MSRP
- $10,499.00
- Sizes
- XXS, XS, S, M, L, XL
- Colors
- Pro Black
- Weight
- 16.71 lb
- Geometry
- 6 manufacturer sizes · Geometry context
- Record coverage
- 16 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001378
Frameset
| Frame Construction | Canyon Endurace CFR-PRO |
|---|---|
| Frame Material | Carbon (CFR) |
| Fork | Canyon FK0137 CF Disc |
| Fork Material | Carbon |
Drivetrain
| Rear Derailleur | Shimano Dura-Ace Di2 |
|---|---|
| Crankset | Shimano Dura-Ace Di2 Powermeter 165mm |
| Bottom Bracket | Shimano Pressfit BB92 |
| Cassette | Shimano Dura-Ace CS-R9200 |
| Chain | Shimano XTR |
Cockpit & Contact Points
| Saddle | Selle Italia SLR Carbon |
|---|---|
| Seatpost | SP0093 VCLS Aero |
Wheels & Tires
| Wheels | Front: DT Swiss ARC 1100 65 mm; Rear: DT Swiss ARC 1100 |
|---|---|
| Front Tire | Pirelli P Zero Race RS TLR 35mm |
| Rear Tire | Pirelli P Zero Race RS TLR 35mm |
| Wheel Size | 700C |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 2XS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|
| Seat tube | 432 mm | 462 mm | 492 mm | 522 mm | 552 mm | 582 mm |
| Effective top tube | 515 mm | 528 mm | 550 mm | 560 mm | 573 mm | 599 mm |
| Head tube | 88 mm | 107 mm | 121 mm | 142 mm | 162 mm | 188 mm |
| Head-tube angle | 69.5° | 71° | 72.8° | 73.25° | 73.3° | 73.5° |
| Seat-tube angle | 72.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Chainstay / rear center | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm | 415 mm |
| Wheelbase | 985 mm | 986 mm | 985 mm | 990 mm | 1003 mm | 1029 mm |
| Bottom-bracket drop | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Reach | 375 mm | 381 mm | 390 mm | 393 mm | 401 mm | 419 mm |
| Stack | 499 mm | 523 mm | 542 mm | 563 mm | 583 mm | 609 mm |
| Crank length | 160 mm | 160 mm | 165 mm | 165 mm | 170 mm | 170 mm |
| Wheel size | 700C | 700C | 700C | 700C | 700C | 700C |
Geometry source: Canyon first-party ProductGroup geometry ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
2XS geometry
Archive context: The seat angle of 72.5° sits toward the more relaxed end. The head angle of 69.5° sits toward the slacker end. Its reach of 375 mm sits toward the longer end.
Compared with 29 distinct road geometries in the XXS-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 2XS geometry XS geometry
Archive context: The seat angle of 73.5° sits toward the more relaxed end. Its reach of 381 mm sits toward the longer end. Its wheelbase of 986 mm sits close to the middle of the group.
Compared with 61 distinct road geometries in the XS-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: The head angle of 72.8° sits toward the steeper end. The seat angle of 73.5° sits toward the more relaxed end. Its reach of 390 mm sits toward the longer end.
Compared with 83 distinct road geometries in the Small-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: The head angle of 73.3° sits toward the steeper end. Its reach of 393 mm sits toward the longer end. The seat angle of 73.5° sits somewhat more relaxed than typical.
Compared with 84 distinct road geometries in the Medium-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: The head angle of 73.3° sits toward the steeper end. Its reach of 401 mm sits somewhat longer than typical. Its wheelbase of 1003 mm sits somewhat shorter than typical.
Compared with 73 distinct road geometries in the Large-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: The head angle of 73.5° sits toward the steeper end. Its reach of 419 mm sits toward the longer end. Its bottom-bracket drop of 73 mm sits somewhat deeper than typical.
Compared with 59 distinct road geometries in the XL-equivalent size cohort from model years 2025–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
Shimano Dura-Ace CS-R9200
Exact archived model
Pirelli P Zero Race RS TLR 35mm
Named tire and published width · wheel diameter from this bicycle
Shimano Pressfit BB92
Named archived component — verify dimensions
More qualified parts (3)
Selle Italia SLR Carbon
Named archived component — verify exact version
Shimano Dura-Ace Di2 Powermeter 165mm
Named archived component — verify exact version
Shimano Dura-Ace Di2
Component family — verify exact version
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesIdentify the installed brake system before riding or ordering parts. Test every installed brake separately at walking speed, confirm it stops firmly and releases cleanly, then inspect its pads, braking surfaces and complete cable or hose path.Inspect the brakes →
- DrivetrainConfirm every shift-system battery charges, every shift control works and the derailleur moves cleanly across the cassette. Make sure the matching shift-system charger is included, then measure chain wear and inspect the cassette teeth.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
- Bottom bracketTurn the cranks slowly, feel for rough bearings and check for side-to-side play. Creaking under load deserves investigation but does not identify the source by itself.Inspect the bottom bracket and shell →
Bike-specific inspection checklist 18 checks based on 4 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Canyon Endurace CFR Di2 · Road · Published sizes: XXS, XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Canyon Endurace CFR-PRO · Fork: Canyon FK0137 CF Disc · Carbon
Drivetrain
Check drivetrain wear →Archived: Rear derailleur: Shimano Dura-Ace Di2 · Crankset: Shimano Dura-Ace Di2 Powermeter 165mm · Bottom bracket: Shimano Pressfit BB92 · Cassette: Shimano Dura-Ace CS-R9200 · Chain: Shimano XTR
Brakes
Inspect the brakes →Wheels and tires
Check wheels and tires →Archived: Wheel size: 700C · Wheels: Front: DT Swiss ARC 1100 65 mm; Rear: DT Swiss ARC 1100 · Front tire: Pirelli P Zero Race RS TLR 35mm · Rear tire: Pirelli P Zero Race RS TLR 35mm
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
