Lowest0.94:1
Highest4.73:1
Total range504%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
2005 Burley Duet
Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · 700c wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #93868- Model year
- 2005
- Category
- Tandem
- Original MSRP
- $2,199.00
- Sizes
- Extra-Small, S, M, L
- Colors
- Firebird, Seafoam
- In this record
- 26 specifications · original MSRP
Model history 10 other years
Browse other years
Compare side by side
Identification clues
2005 archived details
- Published colors
- Firebird, Seafoam
- Frame
- True Temper OX Platinum
- Original equipment
- Tandem Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildTrue Temper OX Platinum · Tandem Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | True Temper OX Platinum |
| Fork | Burley |
| Fork Material | True Temper chromoly, unicrown crown |
Drivetrain
| Component Group | Tandem Mix |
|---|---|
| Shifters | Shimano 105 STI Dual Control |
| Front Derailleur | Shimano 105, bottom-pull/clamp-on 28.6mm |
| Rear Derailleur | Shimano Deore XT SGS |
| Crankset | TruVativ Elita ISIS, 30/42/52 teeth |
| Bottom Bracket | TruVativ ISIS |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Sunrace CN99, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Tektro RX5 Mini-V front/Avid BB-7 disc rear brakes, Shimano 105 STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Cane Creek S-2 |
|---|---|
| Handlebar | TruVativ XR/Ritchey Logic Pro |
| Handlebar Extensions | Not included |
| Stem | TruVativ XR |
| Saddle | Selle Italia Initiale/lady |
| Seatpost | Ritchey Comp |
Wheels & Tires
| Hubs | Shimano Deore XT |
|---|---|
| Rims | Weinmann DPX, 40-hole |
| Spokes | DT Swiss stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 28c Panaracer Pasela |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 28c Panaracer Pasela
Retailer offers
Vittoria Zaffiro Pro V Clincher Tire Black, 700x28
700x28c
Replacement option
Other replacement options (1)
Specialized SW Mondo 2Bliss Tire Black, 700x28
700x28c
Replacement option
Panaracer Pasela on eBaySponsored links
Shimano Deore XT SGS
Shimano 105 STI Dual Control
More parts (2)Fewer parts
Ritchey Comp
Shimano Deore XT
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 28c Panaracer Pasela
- Drivetrain
- 9-speed
- Bottom bracket / shell
- TruVativ ISIS
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Burley · True Temper chromoly, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Tandem Mix · Shifters: Shimano 105 STI Dual Control · Front derailleur: Shimano 105, bottom-pull/clamp-on 28.6mm · Rear derailleur: Shimano Deore XT SGS · Crankset: TruVativ Elita ISIS, 30/42/52 teeth · Bottom bracket: TruVativ ISIS · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Sunrace CN99, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro RX5 Mini-V front/Avid BB-7 disc rear brakes, Shimano 105 STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Weinmann DPX, 40-hole · Hubs: Shimano Deore XT · Front tire: 700 x 28c Panaracer Pasela
Controls and contact points
Archived: Headset: 1 1/8" threadless Cane Creek S-2 · Handlebar: TruVativ XR/Ritchey Logic Pro · Stem: TruVativ XR · Seatpost: Ritchey Comp · Saddle: Selle Italia Initiale/lady · Pedals: Not included
