Lowest1.00:1
Highest4.50:1
Total range450%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×26; rear size isn’t listed.
Velopedia Bicycle Archive
1994 Burley Duet
Original specifications: Shimano Deore LX drivetrain · 700c wheels · legacy reference geometry.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #18002- Model year
- 1994
- Category
- Tandem
- Original MSRP
- $1,650.00
- Sizes
- Captain 20.5"/stoker 18", captain 22"/stoker 19.5", captain 23.5"/stoker 21"
- Geometry
- Legacy reference
- In this record
- 20 specifications · original MSRP · geometry
Model history 10 other years
Browse other years
Compare side by side
Identification clues
1994 archived details
- Frame
- True Temper / 4130 chromoly, oversize
- Original equipment
- Shimano Deore LX
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildTrue Temper / 4130 chromoly, oversize · Shimano Deore LX · 700c wheels
Frameset
| Frame Construction | TIG-welded steel |
|---|---|
| Frame Material | True Temper / 4130 chromoly, oversize |
| Fork | Chromoly, unicrown, oversized |
Drivetrain
| Component Group | Shimano Deore LX |
|---|---|
| Shifters | Shimano SL-BS50 bar-end 7-speed |
| Front Derailleur | Shimano Deore LX |
| Rear Derailleur | Shimano Deore LX |
| Crankset | Suguino GP110 Tandem, 28/44/54 teeth |
| Rear Cogs | 7-speed, 12 - 28 teeth |
| Chain | DID Supershift |
| Pedals | MKS alloy Edge, w/Cateye clips & straps |
Brakes
| Brakes | Suntour XC Pro/ Dia-Compe Blaze Aero brakes, levers |
|---|
Cockpit & Contact Points
| Handlebar | Front: 43cm Modolo rear: 45cm Burley upturn |
|---|---|
| Stem | Front: chromoly Burley O/S rear: SR alloy |
| Saddle | Vetta Lite Gel |
| Seatpost | Kalloy alloy 250mm |
Wheels & Tires
| Hubs | Sanshin Pro Tandem sealed |
|---|---|
| Rims | Chinook CRT16-II, 48-hole |
| Front Tire | 700 x 26c Specialized Transition K4 |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 4 measurements
| Measurement | Legacy reference |
|---|---|
| Head-tube angle | 73° |
| Chainstay / rear center | 438.1 mm |
| Wheelbase | 1729.7 mm |
| Fork offset / rake | 57.1 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 26c Specialized Transition K4
Retailer offers
Pirelli P7 Sport Clincher Tire Black, 700x26
700x26c
Replacement option
Specialized Transition K4 on eBaySponsored links
MKS alloy Edge
w/Cateye clips & straps
Shimano Deore LX
More parts (2)Fewer parts
Shimano Deore LX
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 26c Specialized Transition K4
- Drivetrain
- 7-speed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded steel · Fork: Chromoly, unicrown, oversized
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Deore LX · Shifters: Shimano SL-BS50 bar-end 7-speed · Front derailleur: Shimano Deore LX · Rear derailleur: Shimano Deore LX · Crankset: Suguino GP110 Tandem, 28/44/54 teeth · Rear cogs: 7-speed, 12 - 28 teeth · Chain: DID Supershift
Brakes
Inspect the brakes →Archived: Brakes: Suntour XC Pro/ Dia-Compe Blaze Aero brakes, levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Chinook CRT16-II, 48-hole · Hubs: Sanshin Pro Tandem sealed · Front tire: 700 x 26c Specialized Transition K4
Controls and contact points
Archived: Handlebar: Front: 43cm Modolo rear: 45cm Burley upturn · Stem: Front: chromoly Burley O/S rear: SR alloy · Seatpost: Kalloy alloy 250mm · Saddle: Vetta Lite Gel · Pedals: MKS alloy Edge, w/Cateye clips & straps
