1997 Burley Duet

Archived: Frame: TIG-welded · Fork: Burley · True Temper Tandem chromoly, unicrown crown

• Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.
• Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Archived: Shifters: Shimano 600 Ultegra bar-end · Front derailleur: Sachs Centera, bottom-pull/clamp-on 28.6 mm · Rear derailleur: Shimano Deore XT SGS · Crankset: Sugino Fuse Tandem, 28/42/52 teeth · Bottom bracket: Burley Tandem precision sealed, 117 mm spindle · Rear cogs: 8-speed, 11 - 28 teeth · Chain: Shimano CN-HG50, 1/2 x 3/32"

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Shimano Deore LX M-System brakes, Shimano RX-100 levers

• Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Archived: Wheel size: 700c wheels · Rims: Sun Rims CRT16 II, 48-hole · Hubs: Shimano Tandem · Front tire: 700 x 26c Specialized Transition

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Archived: Headset: 1 1/8" Tange-Seiki Avenger · Handlebar: Burley aluminum drop · Stem: Burley chromoly · Seatpost: Aluminum micro-adjust, 26.6 mm diameter · Saddle: Vetta SL, manganese rails/Vetta SL womens,manganese rails · Pedals: Wellgo WPD-700 (clipless)

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
