1999 Trek 8000 WSD

Original specifications: Mountain Mix drivetrain · 26" wheels · legacy reference geometry.

Share owner experience

Selling this bike? Create a shareable bike record

At a glance

Model year
1999
Category
Mountain
Original MSRP
$1,099.99
Sizes
Womens 13", womens 17", womens 19"
Colors
Pearl White
Geometry
Legacy reference
In this record
26 specifications · archived image · original MSRP · geometry
Archive ID
83589
Model history 6 other years
Campaign

Manufacturer catalog

Published sizes and colors

3 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Womens 13"womens 17"womens 19"

Published colors

Pearl White

Frameset

Frame ConstructionTIG-welded
Frame MaterialAlpha SL aluminum
ForkAnswer Manitou SX, 3.15" travel
Fork MaterialAluminum/magnesium, triple-clamp crown

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore LX RapidFire SL
Front DerailleurShimano Deore LX, top-pull/clamp-on 35.0mm
Rear DerailleurShimano Deore XT
CranksetICON Crankshaft, 22/32/44 teeth
Bottom BracketShimano BB-UN52, 113mm spindle
BB Shell Width73mm English
Rear Cogs9-speed, 11 - 32 teeth
ChainShimano CN-HG72, 1/2 x 3/32"
PedalsBontrager Re-Entry

Brakes

BrakesAvid 1D-20 brakes, Lee Chi LV30E levers

Cockpit & Contact Points

Headset1 1/8" threadless Aheadset SA
HandlebarIcon 2014
StemIcon
SaddleVelo
SeatpostICON Moses, 27.2mm diameter

Wheels & Tires

HubsFront: Bontrager Comp II, Rear: Shimano Deore LX
RimsBontrager Maverick, 28-hole/32-hole
SpokesDT stainless steel, 1.8mm straight gauge
Spoke NipplesBrass nipples
Front TireFront: 26 x 2.10" Bontrager Revolt ST-2 kevlar, Rear: 26 x 1.90" Bontrager Revolt ST-2 kevlar
Wheel Size26" wheels

Historical reference geometry

Geometry

Legacy reference · 6 measurements

This historical geometry describes the model, but the original source does not identify its frame size. Use it as a period reference, not a size-specific fit comparison.

MeasurementLegacy reference
Top tube534 mm
Head-tube angle70°
Seat-tube angle74°
Chainstay / rear center424 mm
Wheelbase1023 mm
Fork offset / rake42 mm

The preserved source contains one model-level geometry set without an identified frame size.

Published drivetrain ratios

Gearing

Chainring ÷ rear sprocket

Lower ratios provide more mechanical advantage for climbing. Higher ratios turn the rear wheel farther with each crank revolution.

Published build44/32/22T · 11–32T · 9-speed
Lowest0.69:1 Highest4.00:1 Total range582%

The bar uses the same mechanical-ratio calculation as Compare. Wheel-dependent speed appears only when the record includes an exact ISO/ETRTO rear tire size; no tire size is assumed.

Parts & serviceability

Find replacement parts

3 top part searches
ChainExact archived part
Shimano CN-HG72, 1/2 x 3/32" Exact archived model
Bottom bracketExact archived part
Shimano BB-UN52, 113mm spindle Exact archived model
PedalsQualified part search
Bontrager Re-Entry Named archived component — verify exact version
More qualified parts (3)
Rear derailleurMatching configuration
Shimano Deore XT Interpreted as Shimano Deore XT · 9-speed · mechanical Named component · published drivetrain speed — verify exact version
ShiftersQualified part search
Shimano Deore LX RapidFire SL Interpreted as Shimano Deore LX · 9-speed · mechanical Named component · published drivetrain speed — verify exact version
SeatpostMatching fit standard
27.2 mm seatpost Published diameter — verify length and setback

Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.

Campaign
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
0 of 20 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 1999 Trek 8000 WSD · Mountain bike, front suspension · Published sizes: Womens 13", womens 17", womens 19"

Archived: Frame: TIG-welded · Fork: Answer Manitou SX, 3.15" travel · Aluminum/magnesium, triple-clamp crown

Archived: Fork: Answer Manitou SX, 3.15" travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore LX RapidFire SL · Front derailleur: Shimano Deore LX, top-pull/clamp-on 35.0mm · Rear derailleur: Shimano Deore XT · Crankset: ICON Crankshaft, 22/32/44 teeth · Bottom bracket: Shimano BB-UN52, 113mm spindle · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG72, 1/2 x 3/32"

Archived: Brakes: Avid 1D-20 brakes, Lee Chi LV30E levers

Archived: Wheel size: 26" wheels · Rims: Bontrager Maverick, 28-hole/32-hole · Hubs: Front: Bontrager Comp II, Rear: Shimano Deore LX · Front tire: Front: 26 x 2.10" Bontrager Revolt ST-2 kevlar, Rear: 26 x 1.90" Bontrager Revolt ST-2 kevlar

Controls and contact points

Archived: Headset: 1 1/8" threadless Aheadset SA · Handlebar: ICON 2014 · Stem: ICON · Seatpost: ICON Moses, 27.2mm diameter · Saddle: Velo · Pedals: Bontrager Re-Entry
