1999 Trek 1200T (01)

Original specifications: Shimano RSX Triple drivetrain · 700c wheels · 25 lb published weight.

Share owner experience

Selling this bike? Create a shareable bike record

At a glance

Model year
1999
Category
Road
Original MSRP
$749.99
Sizes
43cm, 50cm, 54cm, 56cm, 58cm, 60cm
Colors
Titanium
Weight
25 lb
Geometry
Legacy reference
In this record
27 specifications · original MSRP · geometry
Archive ID
83968
Image not available
Campaign

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

43cm50cm54cm56cm58cm60cm

Published colors

Titanium

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum
ForkTrek
Fork MaterialChromoly

Drivetrain

Component GroupShimano RSX Triple
ShiftersShimano RSX STI Dual Control
Front DerailleurShimano RX-100, bottom-pull/clamp-on 31.8mm
Rear DerailleurShimano RSX GS
CranksetSugino RD5000, 30/42/52 teeth
Bottom BracketShimano BB-LP27, 118mm spindle
BB Shell Width68mm English
Rear Cogs7-speed, 11 - 28 teeth
ChainShimano CN-UG50, 1/2 x 3/32"
PedalsResin w/clips & straps

Brakes

BrakesShimano RSX Dual Pivot brakes, Shimano RSX STI levers

Cockpit & Contact Points

Headset1" Tange-Seiki Passage
HandlebarAluminum, drop style
Handlebar ExtensionsNot included
StemChromoly
SaddleTrek
SeatpostAluminum micro-adjust, 27.0mm diameter

Wheels & Tires

HubsShimano RSX
RimsRigida V-Argent, 32-hole
SpokesStainless steel, 1.8mm straight gauge
Spoke NipplesBrass nipples
Front Tire700 x 23c Continental Super Sport 100
Wheel Size700c wheels

Historical reference geometry

Geometry

Legacy reference · 6 measurements

This historical geometry describes the model, but the original source does not identify its frame size. Use it as a period reference, not a size-specific fit comparison.

MeasurementLegacy reference
Top tube555 mm
Head-tube angle73.5°
Seat-tube angle73.5°
Chainstay / rear center415 mm
Wheelbase989 mm
Fork offset / rake47 mm

The preserved source contains one model-level geometry set without an identified frame size.

Published drivetrain ratios

Gearing

Chainring ÷ rear sprocket

Lower ratios provide more mechanical advantage for climbing. Higher ratios turn the rear wheel farther with each crank revolution.

Published build52/42/30T · 11–28T · 7-speed
Lowest1.07:1 Highest4.73:1 Total range441%

The bar uses the same mechanical-ratio calculation as Compare. Wheel-dependent speed appears only when the record includes an exact ISO/ETRTO rear tire size; no tire size is assumed.

Parts & serviceability

Find replacement parts

3 top part searches
ChainExact archived part
Shimano CN-UG50, 1/2 x 3/32" Exact archived model
Front tireMatching fit standard
700 x 23c Continental Super Sport 100 Named tire and published size
Bottom bracketExact archived part
Shimano BB-LP27, 118mm spindle Exact archived model
More qualified parts (2)
SeatpostMatching fit standard
27 mm seatpost Published diameter — verify length and setback
HubsQualified part search
Shimano RSX Named archived component — verify dimensions

Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.

Campaign
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
0 of 19 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 1999 Trek 1200T (01) · Road race & triathlon · Published sizes: 43cm, 50cm, 54cm, 56cm, 58cm, 60cm

Archived: Frame: TIG-welded · Fork: Trek · Chromoly

Archived: Group: Shimano RSX Triple · Shifters: Shimano RSX STI Dual Control · Front derailleur: Shimano RX-100, bottom-pull/clamp-on 31.8mm · Rear derailleur: Shimano RSX GS · Crankset: Sugino RD5000, 30/42/52 teeth · Bottom bracket: Shimano BB-LP27, 118mm spindle · Rear cogs: 7-speed, 11 - 28 teeth · Chain: Shimano CN-UG50, 1/2 x 3/32"

Archived: Brakes: Shimano RSX Dual Pivot brakes, Shimano RSX STI levers

Archived: Wheel size: 700c wheels · Rims: Rigida V-Argent, 32-hole · Hubs: Shimano RSX · Front tire: 700 x 23c Continental Super Sport 100

Controls and contact points

Archived: Headset: 1" Tange-Seiki Passage · Handlebar: Aluminum, drop style · Stem: Chromoly · Seatpost: Aluminum micro-adjust, 27.0mm diameter · Saddle: Trek · Pedals: Resin w/clips & straps
