1998 Trek 930

Original specifications: Mountain Mix drivetrain · 26" wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #77099
Model year
1998
Category
Mountain
Original MSRP
$559.99
Sizes
13", 16.5", 18", 19.5", 21", 22.5"
Colors
Metallized Green
Geometry
Legacy reference
In this record
27 specifications · archived image · original MSRP · geometry
Model history 6 other years

Browse other years

Compare side by side

Identification clues

1998 archived details

Published colors
Metallized Green
Frame
True Temper chromoly, triple-butted
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildTrue Temper chromoly, triple-butted · Mountain Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

13"16.5"18"19.5"21"22.5"

Published colors

Metallized Green

Frameset

Frame ConstructionTIG-welded
Frame MaterialTrue Temper chromoly, triple-butted
ForkRock Shox Indy S
Fork MaterialAluminum/magnesium, triple-clamp crown

Drivetrain

Component GroupMountain Mix
ShiftersGrip Shift ESP 700
Front DerailleurShimano Alivio top-swing, top-pull
Rear DerailleurGrip Shift ESP 7.0
CranksetSugino Impel 250, 24/34/42 teeth
Bottom BracketShimano BB-LP27, 113mm spindle
BB Shell Width73mm English
Rear Cogs8-speed, 11 - 28 teeth
ChainSachs PC-21, 1/2 x 3/32"
PedalsAluminum cage w/clips & straps

Brakes

BrakesLee Chi TX22 brakes, Lee Chi LV77E levers

Cockpit & Contact Points

Headset1 1/8" threadless Aheadset Kontak ST-2
HandlebarSystem 1
Handlebar ExtensionsNot included
StemSystem 1
SaddleVelo Crossbow
SeatpostAluminum micro-adjust, 27.2mm diameter

Wheels & Tires

HubsFront: System 1 suspension, Rear: aluminum quick release
RimsMatrix Guru, 32-hole
SpokesDT stainless steel, 2.0mm straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.10" IRC Mythos XC
Wheel Size26" wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube530.9 mm
Head-tube angle70.5°
Seat-tube angle74°
Chainstay / rear center431.8 mm
Wheelbase1016 mm
Fork offset / rake40.6 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes42/34/24T · 11–28T · 8-speed
Lowest0.86:1 Highest3.82:1 Total range445%
Estimated speed At 90 RPM Lowest gear6.0 mph Highest gear26.8 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
Sachs PC-21

1/2 x 3/32"

Seatpost · Original
Aluminum micro-adjust

27.2mm diameter

Front tire · Original
26 x 2.10" IRC Mythos XC
More parts (2)Fewer parts
Bottom bracket · Original
Shimano BB-LP27

113mm spindle

Front derailleur · Original
Shimano Alivio top-swing

top-pull

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" IRC Mythos XC
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Shimano BB-LP27, 113mm spindle · 73mm English
Equipment inspection checks 12 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 12 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Rock Shox Indy S · Aluminum/magnesium, triple-clamp crown

Archived: Fork: Rock Shox Indy S

Archived: Group: Mountain Mix · Shifters: Grip Shift ESP 700 · Front derailleur: Shimano Alivio top-swing, top-pull · Rear derailleur: Grip Shift ESP 7.0 · Crankset: Sugino Impel 250, 24/34/42 teeth · Bottom bracket: Shimano BB-LP27, 113mm spindle · Rear cogs: 8-speed, 11 - 28 teeth · Chain: Sachs PC-21, 1/2 x 3/32"

Archived: Brakes: Lee Chi TX22 brakes, Lee Chi LV77E levers

Archived: Wheel size: 26" wheels · Rims: Matrix Guru, 32-hole · Hubs: Front: System 1 suspension, Rear: aluminum quick release · Front tire: 26 x 2.10" IRC Mythos XC

Controls and contact points

Archived: Headset: 1 1/8" threadless Aheadset Kontak ST-2 · Handlebar: System 1 · Stem: System 1 · Seatpost: Aluminum micro-adjust, 27.2mm diameter · Saddle: Velo Crossbow · Pedals: Aluminum cage w/clips & straps
