Velopedia Bicycle Archive

Surly Disc Trucker

Touring bicycle from the Velopedia specification archive.

Model year: Not published by manufacturer
Original MSRP: From $2,099.00
Sizes: 56cm; 58cm; 60cm; 62cm; 64cm; 42cm; 46cm; 50cm; 52cm; 54cm
Colors: Grandpa's Khakis; Pea Lime Soup; Hi-Viz Black
Weight: 29lb 13oz for 56cm | 28 lb 7 oz for 52cm
Geometry: 5 manufacturer sizes
Archive ID: 900000360
Catalog verified: August 12, 2026

Current market

19 close matches

Used asking Insufficient sample1 close used listing found

New asking $2,174.00Median asking · $1,599.00–$2,274.00 · 18 listings

View market details

Frameset

Frame Construction	Surly Disc Trucker - 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated \| Surly Disc Trucker: 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Frame Material	Steel
Fork	Surly Disc Trucker - 100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, brazed lugs, E.D. coated \| Surly Disc Trucker: 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Fork Material	Steel

Drivetrain

Shifters	Shimano CUES U6030 \| Shimano Sora 3x9
Front Derailleur	Shimano CUES U6030 \| Shimano CUES U6010 \| Shimano Sora R3030
Rear Derailleur	Shimano CUES 6020 SGS \| Shimano CUES U6020 SGS \| Shimano Alivio M4000 SGS
Crankset	Shimano CUES U6010, 46/30T \| Shimano CUES U6000, 46/30T \| Shimano Alivio 48x36x26t
Bottom Bracket	Shimano UR400 BSA \| Shimano SM-BB52 \| Shimano BB-RS500
Cassette	Shimano CUES LG400, 11-39t, 10-speed \| Shimano Alivio, 11-34t, 9 speed
Chain	Shimano LG500 \| KMC X9

Brakes

Brakes	Brake Calipers: Shimano CUES U6030; Brake Levers: Shimano CUES U6030; Rotors: Shimano RT26 180/180, 6-Bolt \| Brake Calipers: TRP Spyre C; Brake Levers: Shimano Sora; Rotors: TRP 160mm front and rear

Cockpit & Contact Points

Headset	FSA Orbit MX \| Cane Creek 40
Handlebar	Surly Truckstop Bar
Stem	Promax DA-296, 31.8mm \| ProMax 31.8 4 bolt
Saddle	WTB Volt Sport
Seatpost	Promax 27.2 x 350mm \| ProMax 27.2, 350L, non-offset (42-50), offset (52-64)

Wheels & Tires

Hubs	(F) Novatec 12 x 100mm, 6-bolt, 36h / (R) Novatec 12 x 142mm, 6-bolt, 36h \| (F) Novatec 12x100, 6 bolt, 36H / (R) Novatec 12x142, 6 bolt, 36H
Rims	Alex Adventurer 2 700c, 36h \| Alex Adventurer 2 26", 36h
Spokes	14G Black \| 14 Gauge Stainless
Front Tire	Surly ExtraTerrestrial 700c x 41mm, 60tpi \| Surly ExtraTerrestrial 26" x 46mm, 60tpi \| Surly ExtraTerrestrial 700x41 \| Surly ExtraTerrestrial 26x46
Rear Tire	Surly ExtraTerrestrial 700c x 41mm, 60tpi \| Surly ExtraTerrestrial 26" x 46mm, 60tpi \| Surly ExtraTerrestrial 700x41 \| Surly ExtraTerrestrial 26x46
Wheel Size	700C; 26" \| 26"; 700C

Size-specific frame data

Geometry

5 sizes · 16 measurements

Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.

Measurement	56cm	58cm	60cm	62cm	64cm
Seat tube	560 mm	580 mm	600 mm	620 mm	640 mm
Effective top tube	575 mm	590 mm	605 mm	620 mm	635 mm
Head tube	175 mm	195 mm	215 mm	235 mm	250 mm
Head-tube angle	72°	72°	72°	72°	72°
Seat-tube angle	73°	72.5°	72.5°	72°	72°
Chainstay / rear center	450 mm	450 mm	450 mm	450 mm	450 mm
Wheelbase	1051 mm	1060 mm	1075.5 mm	1084 mm	1090 mm
Bottom-bracket drop	80 mm	80 mm	80 mm	80 mm	80 mm
Reach	387.5 mm	391 mm	400 mm	402 mm	412.5 mm
Stack	613 mm	632 mm	651.5 mm	670.5 mm	685 mm
Standover height	813 mm	831 mm	850 mm	869 mm	885 mm
Fork offset / rake	45 mm	45 mm	45 mm	45 mm	45 mm
Fork length / axle-to-crown	390 mm	390 mm	390 mm	390 mm	390 mm
Crank length	175 mm	175 mm	175 mm	175 mm	175 mm
Stem length	100 mm	100 mm	110 mm	120 mm	120 mm
Handlebar width	480 mm	480 mm	480 mm	480 mm	480 mm

Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
