Velopedia Bicycle Archive

Surly Disc Trucker 26" - Grandpa's Khakis

Touring bicycle from the Velopedia specification archive.

Model year: Not published by manufacturer
Original MSRP: $2,199.00
Sizes: 42cm; 46cm; 50cm; 52cm; 54cm
Colors: Grandpa's Khakis
Weight: 28 lb 7 oz for 52cm
Geometry: 5 manufacturer sizes
Archive ID: 900000361
Catalog verified: August 12, 2026

Current market

0 close matches

Used asking No listingsNo close matches in this condition.

New asking No listingsNo close matches in this condition.

View market details

Frameset

Frame Construction	Surly Disc Trucker - 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Frame Material	Steel
Fork	Surly Disc Trucker - 100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, brazed lugs, E.D. coated
Fork Material	Steel

Drivetrain

Shifters	Shimano CUES U6030
Front Derailleur	Shimano CUES U6010
Rear Derailleur	Shimano CUES U6020 SGS
Crankset	Shimano CUES U6000, 46/30T
Bottom Bracket	Shimano UR400 BSA
Cassette	Shimano CUES LG400, 11-39t, 10-speed
Chain	Shimano LG500

Brakes

Brakes	Brake Calipers: Shimano CUES U6030; Brake Levers: Shimano CUES U6030; Rotors: Shimano RT26 180/180, 6-Bolt

Cockpit & Contact Points

Headset	FSA Orbit MX
Handlebar	Surly Truckstop
Stem	Promax DA-296, 31.8mm
Saddle	WTB Volt Wide OR WTB Rocket Medium Fusion
Seatpost	Promax 27.2 x 350mm

Wheels & Tires

Hubs	(F) Novatec 12 x 100mm, 6-bolt, 36h / (R) Novatec 12 x 142mm, 6-bolt, 36h
Rims	Alex Adventurer 2 26", 36h
Spokes	14 Gauge Stainless
Front Tire	Surly ExtraTerrestrial 26" x 46mm, 60tpi
Rear Tire	Surly ExtraTerrestrial 26" x 46mm, 60tpi
Wheel Size	26"; 700C

Size-specific frame data

Geometry

5 sizes · 16 measurements

Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.

Measurement	42cm	46cm	50cm	52cm	54cm
Seat tube	420 mm	460 mm	500 mm	520 mm	540 mm
Effective top tube	500 mm	515 mm	530 mm	545 mm	560 mm
Head tube	125 mm	130 mm	170 mm	185 mm	205 mm
Head-tube angle	70°	70°	71°	71°	71°
Seat-tube angle	75°	74.5°	74°	73.5°	73°
Chainstay / rear center	450 mm	450 mm	450 mm	450 mm	450 mm
Wheelbase	1026 mm	1037 mm	1040 mm	1050 mm	1060.5 mm
Bottom-bracket drop	50 mm	50 mm	50 mm	50 mm	50 mm
Reach	362 mm	371 mm	369 mm	374.5 mm	378 mm
Stack	515 mm	520 mm	561 mm	575.5 mm	594.5 mm
Standover height	710 mm	731 mm	766 mm	782 mm	800 mm
Fork offset / rake	45 mm	45 mm	45 mm	45 mm	45 mm
Fork length / axle-to-crown	376 mm	376 mm	376 mm	376 mm	376 mm
Crank length	170 mm	170 mm	170 mm	170 mm	170 mm
Stem length	70 mm	70 mm	70 mm	90 mm	100 mm
Handlebar width	420 mm	420 mm	420 mm	450 mm	450 mm

Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
