Velopedia Bicycle Archive
2026 Spot Rocker V2 Singlespeed 5-star
Original manufacturer specifications including 29 wheels, S: 20.7 | M: 20.9 | L: 21.0 | XL: 21.1 published weight, geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2026
- Category
- Mountain
- Original MSRP
- $5,299.00
- Sizes
- S, M, L, XL
- Colors
- Black, Twilight Purple
- Weight
- S: 20.7 | M: 20.9 | L: 21.0 | XL: 21.1
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 18 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001726
Frameset
| Frame Construction | Spot carbon frame — Rocker’s all-carbon frame |
|---|---|
| Frame Material | Carbon |
| Fork | RockShox SID Select | 35mm stanchions | 120mm travel | Charger RL | 44mm Rake | Boost 15x110 |
Drivetrain
| Crankset | SRAM GX Eagle | B148 | DUB | 175mm | 46t |
|---|---|
| Bottom Bracket | SRAM DUB BSA MTB73 |
| Cassette | Gates CDX CenterTrack 46t | Gates CDX CenterTrack SL 28t |
| Chain | Gates CDX CenterTrack 118t | Black |
Brakes
| Brakes | (F) SRAM Motive V2 Bronze | 180mm HS2 rotor | 6-Bolt / (R) SRAM Motive V2 Bronze | 160mm HS2 rotor | 6-Bolt |
|---|
Cockpit & Contact Points
| Headset | Cane Creek 50 | ZS44/ZS56 ZS44 upper | ZS56 lower |
|---|---|
| Handlebar | OneUp Aluminum | 35mm Clamp | 20mm Rise | Sweep: 8 ° Back | 5° Up | Widths: XL: 800mm | LG: 800mm | MD: 780mm | SM: 760mm |
| Stem | Race Face Aeffect | 50mm |
| Saddle | SDG Bel-Air V3 |
| Seatpost | BikeYoke Revive | Travel: 185mm for XL and Large | 160mm for Medium | 125mm for Small | Diameter: 31.6mm |
Wheels & Tires
| Wheels | (F) DT Swiss | M1900 SPLINE | 15x110 | 29” | 6-Bolt / (R) DT Swiss | M1900 SPLINE | 12x148 | 29” | HG | 6-Bolt |
|---|---|
| Front Tire | 29: Schwalbe Rick 29x2.4 |
| Rear Tire | 29: Schwalbe Rick 29x2.4 |
| Wheel Size | 29 |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | Small | Medium | Large | X-Large |
|---|---|---|---|---|
| Seat tube | 380 mm | 410 mm | 460 mm | 510 mm |
| Top tube | 567 mm | 601 mm | 634 mm | 667 mm |
| Head tube | 90 mm | 105 mm | 120 mm | 130 mm |
| Head-tube angle | 67° | 67° | 67° | 67° |
| Seat-tube angle | 75.5° | 75.5° | 75.5° | 75.5° |
| Chainstay / rear center | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1141 mm | 1177 mm | 1213 mm | 1247 mm |
| Bottom-bracket drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Bottom-bracket height | 320 mm | 320 mm | 320 mm | 320 mm |
| Reach | 410 mm | 440 mm | 470 mm | 500 mm |
| Stack | 607 mm | 621 mm | 635 mm | 644 mm |
| Standover height | 741 mm | 741 mm | 782 mm | 782 mm |
| Front center | 696 mm | 732 mm | 768 mm | 802 mm |
Geometry source: Spot first-party size geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
Small geometry
Archive context: Its reach of 410 mm sits toward the shorter end. Its bottom-bracket drop of 50 mm sits toward the deeper-drop end. The head angle of 67° sits somewhat steeper than typical.
Compared with 182 distinct mountain geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Medium geometry
Archive context: Its reach of 440 mm sits toward the shorter end. The head angle of 67° sits toward the steeper end. Its bottom-bracket drop of 50 mm sits somewhat deeper than typical.
Compared with 183 distinct mountain geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Large geometry
Archive context: The head angle of 67° sits somewhat steeper than typical. Its bottom-bracket drop of 50 mm sits somewhat deeper than typical. Its reach of 470 mm sits somewhat shorter than typical.
Compared with 180 distinct mountain geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.X-Large geometry
Archive context: The head angle of 67° sits toward the steeper end. Its bottom-bracket drop of 50 mm sits somewhat deeper than typical. Its wheelbase of 1247 mm sits somewhat shorter than typical.
Compared with 153 distinct mountain geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Parts & serviceability
Find replacement parts
More qualified parts (1)
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Spot Rocker V2 Singlespeed 5-star · Mountain · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Spot carbon frame — Rocker’s all-carbon frame · Fork: RockShox SID Select | 35mm stanchions | 120mm travel | Charger RL | 44mm Rake | Boost 15x110
Suspension
Evaluate the suspension →Archived: Fork: RockShox SID Select | 35mm stanchions | 120mm travel | Charger RL | 44mm Rake | Boost 15x110
Drivetrain
Check drivetrain wear →Archived: Crankset: SRAM GX Eagle | B148 | DUB | 175mm | 46t · Bottom bracket: SRAM DUB BSA MTB73 · Cassette: Gates CDX CenterTrack 46t | Gates CDX CenterTrack SL 28t · Chain: Gates CDX CenterTrack 118t | Black
Brakes
Inspect the brakes →Archived: Brakes: (F) SRAM Motive V2 Bronze | 180mm HS2 rotor | 6-Bolt / (R) SRAM Motive V2 Bronze | 160mm HS2 rotor | 6-Bolt
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29 · Wheels: (F) DT Swiss | M1900 SPLINE | 15x110 | 29” | 6-Bolt / (R) DT Swiss | M1900 SPLINE | 12x148 | 29” | HG | 6-Bolt · Front tire: 29: Schwalbe Rick 29x2.4 · Rear tire: 29: Schwalbe Rick 29x2.4
Controls and contact points
Archived: Headset: Cane Creek 50 | ZS44/ZS56 ZS44 upper | ZS56 lower · Handlebar: OneUp Aluminum | 35mm Clamp | 20mm Rise | Sweep: 8 ° Back | 5° Up | Widths: XL: 800mm | LG: 800mm | MD: 780mm | SM: 760mm · Stem: Race Face Aeffect | 50mm · Seatpost: BikeYoke Revive | Travel: 185mm for XL and Large | 160mm for Medium | 125mm for Small | Diameter: 31.6mm · Saddle: SDG Bel-Air V3
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
