2027 Specialized S-Works Stumpjumper 15 EVO
Mountain bicycle from the Velopedia specification archive.
- Original MSRP
- $9,999.99
- Sizes
- S1, S2, S3, S4, S5, S6
- Colors
- Gloss Metallic White Silver, Gloss Charcoal Tint
- Weight
- 14.05 kg (30 lb, 15.6 oz)
- Geometry
- 6 manufacturer sizes · Ride analysis
- Archive ID
- 900000006
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Velopedia analysis
What the specifications mean
Suspension at both ends means fork and shock setup should be considered together; mismatched sag or rebound can leave the front and rear reacting very differently. Both 27.5- and 29-inch wheels appear in the record, but it does not establish a mixed front/rear build; confirm the correct diameter for the selected frame size. Electronic shifting removes the usual shift cable but adds a separate battery and controls, while the 520% cassette range describes how much gearing is available.
Suspension setup
Front + rear
Fork and shock pressure, sag and rebound should be balanced and recorded independently.
Wheel system
27.5 / 29 options
Both diameters are documented, but the archive does not prove a mixed front/rear setup.
Drivetrain
Electronic · 520% range
Shift-system battery state joins derailleur setup and sprocket compatibility as a troubleshooting variable.
Brake service
Hydraulic disc
Pad and rotor condition plus the correct bleed fluid are the primary service checks.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesBoth levers should feel firm and return cleanly. Check for fluid around the levers and calipers, inspect pad thickness and contamination, and look for worn or bent rotors.Inspect the brakes →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- DrivetrainConfirm every shift-system battery charges, every shift control works and the derailleur moves cleanly across the cassette. Make sure the matching shift-system charger is included, then measure chain wear and inspect the cassette teeth.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 23 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Specialized S-Works Stumpjumper 15 EVO · Mountain · Published sizes: S1, S2, S3, S4, S5, S6
Frame and fork
Inspect the frame and fork →Archived: Frame: FACT 11m carbon chassis, rear-end and link, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel · Fork: All New SRAM Rockshox Lyrik Ultimate, 29" 160mm (S2-S6)
Suspension
Evaluate the suspension →Archived: Fork: All New SRAM Rockshox Lyrik Ultimate, 29" 160mm (S2-S6) · Rear shock: All New Rockshox Super Deluxe Ultimate GENIE, RC2T damper with (LSC) Low Speed Compression and (HSC) High Speed Compression, GENIE adjustable airspring, rebound adjust, 210x55mm
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM AXS Pod Ultimate with Discrete Clamp · Rear derailleur: SRAM XX Eagle Transmission Derailleur · Crankset: SRAM XX Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline · Bottom bracket: SRAM DUB Threaded Wide · Cassette: SRAM CS-1299, 12 speed, 10-52t · Chain: SRAM XX Eagle Transmission 12-Speed Flattop Chain
Brakes
Inspect the brakes →Archived: Brakes: (F) SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disc, 220mm rotor / (R) SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disc, 200mm rotor
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29/27.5; 29 · Front tire: Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29X2.4 · Rear tire: Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
Controls and contact points
Archived: Handlebar: Deity Speedway Carbon, 5-degree upsweep, 9-degree backsweep. S1-S2: 810 width, 30mm rise: S3-S6: 810 width, 50mm rise · Stem: Deity, 35mm clamp, 42mm length · Seatpost: RockShox, Reverb AXS, 34.9, S1: 125mm, S2: 150mm, S3: 175mm, S4-S5: 200mm, S6:225mm · Saddle: Specialized S-Works Power Mirror, Ti Rails, 143mm/155mm
Before and during the test ride
Follow the full used-bike inspection order →Interpretation based on the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | FACT 11m carbon chassis, rear-end and link, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | All New SRAM Rockshox Lyrik Ultimate, 29" 160mm (S2-S6) |
| Rear Shock | All New Rockshox Super Deluxe Ultimate GENIE, RC2T damper with (LSC) Low Speed Compression and (HSC) High Speed Compression, GENIE adjustable airspring, rebound adjust, 210x55mm |
Drivetrain
| Shifters | SRAM AXS Pod Ultimate with Discrete Clamp |
|---|---|
| Rear Derailleur | SRAM XX Eagle Transmission Derailleur |
| Crankset | SRAM XX Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline |
| Bottom Bracket | SRAM DUB Threaded Wide |
| Cassette | SRAM CS-1299, 12 speed, 10-52t |
| Chain | SRAM XX Eagle Transmission 12-Speed Flattop Chain |
Brakes
| Brakes | (F) SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disc, 220mm rotor / (R) SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disc, 200mm rotor |
|---|
Cockpit & Contact Points
| Handlebar | Deity Speedway Carbon, 5-degree upsweep, 9-degree backsweep. S1-S2: 810 width, 30mm rise: S3-S6: 810 width, 50mm rise |
|---|---|
| Stem | Deity, 35mm clamp, 42mm length |
| Saddle | Specialized S-Works Power Mirror, Ti Rails, 143mm/155mm |
| Seatpost | RockShox, Reverb AXS, 34.9, S1: 125mm, S2: 150mm, S3: 175mm, S4-S5: 200mm, S6:225mm |
Wheels & Tires
| Wheels | (F) Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 Hydra 2 Hub, 15x110mm, 28h, DT Swiss Revolite Spokes, 6 bolt / (R) Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 Hydra 2 Hub, 12x148mm, 28h, DT Swiss Revolite Spokes, 6 bolt |
|---|---|
| Front Tire | Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29X2.4 |
| Rear Tire | Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4" |
| Wheel Size | 29/27.5; 29 |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S1 | S2 | S3 | S4 | S5 | S6 |
|---|---|---|---|---|---|---|
| Seat tube | 385 mm | 385 mm | 405 mm | 425 mm | 445 mm | 465 mm |
| Seat-tube angle | 77.7° | 76.5° | 76.5° | 76° | 76° | 76° |
| Chainstay / rear center | 430 mm | 432 mm | 435 mm | 435 mm | 445 mm | 445 mm |
| Wheelbase | 1153 mm | 1186 mm | 1217 mm | 1249 mm | 1290 mm | 1327 mm |
| Bottom-bracket drop | 38 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Bottom-bracket height | 337 mm | 340 mm | 340 mm | 340 mm | 340 mm | 340 mm |
| Reach | 400 mm | 420 mm | 445 mm | 470 mm | 495 mm | 525 mm |
| Stack | 611 mm | 621 mm | 630 mm | 644 mm | 658 mm | 671 mm |
| Front center | 724 mm | 755 mm | 785 mm | 816 mm | 848 mm | 884 mm |
| Trail | 133 mm | 134 mm | 134 mm | 134 mm | 134 mm | 134 mm |
| Crank length | 165 mm | 165 mm | 165 mm | 170 mm | 170 mm | 170 mm |
| Stem length | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Handlebar width | 810 mm | 810 mm | 810 mm | 810 mm | 810 mm | 810 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry interpretation
What this geometry means
S1 geometry
Riding position
The 611 mm stack is tall relative to the 400 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. Its 77.7° effective seat angle places the seated rider relatively forward, a layout that generally helps keep body weight centered on steep climbs.
Handling tendencies
The manufacturer lists 133 mm of trail. More trail generally increases self-centering and stability, while less trail generally makes steering respond more quickly to rider input. A 430 mm rear center is compact, which tends to make rear-wheel weight shifts and tight direction changes easier than a long-rear-center layout.
Archive context
Its reach of 400 mm sits toward the shorter end. The seat angle of 77.7° sits toward the steeper end. Its stack of 611 mm sits somewhat taller than typical.
S2 geometry
Riding position
The 621 mm stack is tall relative to the 420 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. Its 76.5° effective seat angle places the seated rider relatively forward, a layout that generally helps keep body weight centered on steep climbs.
Handling tendencies
The manufacturer lists 134 mm of trail. More trail generally increases self-centering and stability, while less trail generally makes steering respond more quickly to rider input.
Archive context
Its reach of 420 mm sits toward the shorter end. Its trail of 134 mm sits somewhat higher than typical. Its stack of 621 mm sits somewhat taller than typical.
S3 geometry
Riding position
The 630 mm stack is tall relative to the 445 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. Its 76.5° effective seat angle places the seated rider relatively forward, a layout that generally helps keep body weight centered on steep climbs.
Handling tendencies
The manufacturer lists 134 mm of trail. More trail generally increases self-centering and stability, while less trail generally makes steering respond more quickly to rider input.
Archive context
Its reach of 445 mm sits toward the shorter end. Its trail of 134 mm sits somewhat higher than typical. Its stack of 630 mm sits somewhat taller than typical.
S4 geometry
Riding position
A 470 mm reach paired with 644 mm of stack gives this size a moderate frame proportion: roomy enough when standing without pushing strongly toward either a very low or very upright front end. Its 76° effective seat angle places the seated rider relatively forward, a layout that generally helps keep body weight centered on steep climbs.
Handling tendencies
The manufacturer lists 134 mm of trail. More trail generally increases self-centering and stability, while less trail generally makes steering respond more quickly to rider input.
Archive context
Its stack of 644 mm sits toward the taller end. Its reach of 470 mm sits toward the shorter end. Its trail of 134 mm sits somewhat higher than typical.
S5 geometry
Riding position
A 495 mm reach paired with 658 mm of stack gives this size a moderate frame proportion: roomy enough when standing without pushing strongly toward either a very low or very upright front end. Its 76° effective seat angle places the seated rider relatively forward, a layout that generally helps keep body weight centered on steep climbs.
Handling tendencies
The manufacturer lists 134 mm of trail. More trail generally increases self-centering and stability, while less trail generally makes steering respond more quickly to rider input.
Archive context
Its stack of 658 mm sits toward the taller end. The chainstay of 445 mm sits toward the longer rear-center end. Its reach of 495 mm sits somewhat shorter than typical.
S6 geometry
Riding position
With 525 mm of reach and 671 mm of stack, the frame has a relatively long, low proportion that should leave plenty of room when standing and put the front end toward the lower side of modern mountain-bike fit. Its 76° effective seat angle places the seated rider relatively forward, a layout that generally helps keep body weight centered on steep climbs.
Handling tendencies
The manufacturer lists 134 mm of trail. More trail generally increases self-centering and stability, while less trail generally makes steering respond more quickly to rider input.
Archive context
Its stack of 671 mm sits toward the taller end. Its reach of 525 mm sits somewhat longer than typical. The seat angle of 76° sits somewhat more relaxed than typical.
Across the size range
From S1 to S6, reach grows by 125 mm and stack by 60 mm, showing how the frame becomes both longer and taller through the published size range. Chainstay length grows from 430 to 445 mm across the range. That size-specific rear-center strategy helps the larger frames grow at both ends instead of adding all of their length ahead of the bottom bracket.
Geometry describes frame proportions and likely tendencies, not a ride test. Rider proportions, cockpit setup, tires, suspension settings, wheel configuration, and component choices can materially change how a bicycle fits and feels.
Gallery
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
