2027 Specialized Epic 9 Comp

Original specifications: 11.78 kg (25 lb, 15.5 oz) published weight · geometry for 4 published sizes.

Share owner experience

Selling this bike? Create a shareable bike record

At a glance

Model year
2027
Category
Mountain
Original MSRP
$5,699.99
Sizes
S, M, L, XL
Colors
Satin Cast Blue Metallic, Gloss Ruby Metallic
Weight
11.78 kg (25 lb, 15.5 oz)
Geometry
4 manufacturer sizes
In this record
20 specifications · 8 archived images · original MSRP · geometry
Archive ID
900000949
Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

4 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMLXL

Published colors

Satin Cast Blue MetallicGloss Ruby Metallic

Frameset

Frame ConstructionFACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel, Optimized for wireless drivetrain
Frame MaterialCarbon Fiber
ForkRockShox SID Select, Ride Dynamics developed 3 position, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Rear ShockRockShox SIDLuxe Select+, Ride Dynamics developed 3 position, TwistLoc remote adjust, Solo Air, 190x45mm

Drivetrain

ShiftersSRAM AXS POD Controller
Rear DerailleurSRAM S1000 Eagle AXS
CranksetSRAM S1000 Eagle, DUB, SM:165mm, M-XL:170mm, 34T
Bottom BracketSRAM DUB Threaded Wide
CassetteSRAM 12-speed,10-52t
ChainSRAM 70 Transmission 12-Speed Flattop Chain

Brakes

Brakes(F) SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 180mm rotor / (R) SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 160mm rotor

Cockpit & Contact Points

HandlebarSpecialized Alloy Minirise, 10mm rise, 750mm, 35mm clamp
StemRoval Alloy XC 2-bolt stem, 60mm/70mm
SaddleBody Geometry Power Comp, chrome alloy rails
SeatpostX-Fusion Manic, 30.9, SM: 125mm, M: 150mm, L-XL: 170mm Travel, 0mm offset

Wheels & Tires

Hubs(F) Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h / (R) Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
RimsSpecialized Alloy 29, 27mm internal width, tubeless
SpokesDT Swiss Elemental
Front TireSpecialized Fast Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35
Rear TireSpecialized Air Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35

Geometry

4 sizes · 18 measurements

Frame measurements by size.

All geometry measurements4 sizes · 18 measurements
MeasurementSMLXL
Seat tube390 mm410 mm455 mm505 mm
Effective top tube568 mm601 mm634 mm666 mm
Head tube92 mm105 mm120 mm150 mm
Head-tube angle65.9°65.9°65.9°65.9°
Seat-tube angle76°76°76°76°
Chainstay / rear center435 mm435 mm438 mm442 mm
Wheelbase1148 mm1184 mm1223 mm1264 mm
Bottom-bracket drop42 mm40 mm40 mm40 mm
Bottom-bracket height333 mm335 mm335 mm335 mm
Reach420 mm450 mm480 mm505 mm
Stack594 mm604 mm618 mm645 mm
Fork offset / rake44 mm44 mm44 mm44 mm
Front center716 mm752 mm788 mm823 mm
Trail120 mm120 mm120 mm120 mm
Fork length / axle-to-crown531 mm531 mm531 mm531 mm
Crank length165 mm170 mm170 mm170 mm
Stem length60 mm70 mm70 mm70 mm
Handlebar width760 mm760 mm760 mm760 mm

Measurements may vary by configuration, wheel size, or frame setting where noted in the published chart.

Gearing

Chainring ÷ rear sprocket

Lower ratios provide more mechanical advantage for climbing. Higher ratios turn the rear wheel farther with each crank revolution.

All published sizes34T · 10–52T · 12-speed
Lowest0.65:1 Highest3.40:1 Total range520%
Campaign

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
SRAM 70 Transmission 12-Speed Flattop Chain
Cassette · Original
SRAM 12-speed,10-52t
Bottom bracket · Original
SRAM DUB Threaded Wide
More parts (3)
Crankset · Original
SRAM S1000 Eagle, DUB, SM:165mm, M-XL:170mm, 34T
Rear derailleur · Original
SRAM S1000 Eagle AXS Search: SRAM S1000 12-speed electronic rear derailleur
Handlebar · Original
Specialized Alloy Minirise, 10mm rise, 750mm, 35mm clamp

Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases.

Campaign
Bike-specific inspection checklist 23 checks based on 6 archived component groups Open checklistClose checklist
0 of 23 checked Progress stays in this browser for this bike.

This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.

Archived: 2027 Specialized Epic 9 Comp · Mountain · Published sizes: S, M, L, XL

Archived: Frame: FACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel, Optimized for wireless drivetrain · Fork: RockShox SID Select, Ride Dynamics developed 3 position, Debon Air, 15x110mm, 44mm offset, 120mm Travel

Archived: Fork: RockShox SID Select, Ride Dynamics developed 3 position, Debon Air, 15x110mm, 44mm offset, 120mm Travel · Rear shock: RockShox SIDLuxe Select+, Ride Dynamics developed 3 position, TwistLoc remote adjust, Solo Air, 190x45mm

Archived: Shifters: SRAM AXS POD Controller · Rear derailleur: SRAM S1000 Eagle AXS · Crankset: SRAM S1000 Eagle, DUB, SM:165mm, M-XL:170mm, 34T · Bottom bracket: SRAM DUB Threaded Wide · Cassette: SRAM 12-speed,10-52t · Chain: SRAM 70 Transmission 12-Speed Flattop Chain

Archived: Brakes: (F) SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 180mm rotor / (R) SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 160mm rotor

Archived: Rims: Specialized Alloy 29, 27mm internal width, tubeless · Hubs: (F) Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h / (R) Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h · Front tire: Specialized Fast Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35 · Rear tire: Specialized Air Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35

Controls and contact points

Archived: Handlebar: Specialized Alloy Minirise, 10mm rise, 750mm, 35mm clamp · Stem: Roval Alloy XC 2-bolt stem, 60mm/70mm · Seatpost: X-Fusion Manic, 30.9, SM: 125mm, M: 150mm, L-XL: 170mm Travel, 0mm offset · Saddle: Body Geometry Power Comp, chrome alloy rails
