Velopedia Bicycle Archive
2025 Specialized Crux DSW Comp
Original specifications: 9.37 kg (20 lb, 10.5 oz) published weight · geometry for 6 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900001040- Model year
- 2025
- Category
- Gravel & Cyclocross
- Original MSRP
- $2,799.99
- Sizes
- 49, 52, 54, 56, 58, 61
- Colors
- Gloss Birch / Clay, Satin Smoke / Oak Green
- Weight
- 9.37 kg (20 lb, 10.5 oz)
- Geometry
- 6 manufacturer sizes
- In this record
- 18 specifications · 8 archived images · original MSRP · geometry
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2025 archived details
- Published colors
- Gloss Birch / Clay, Satin Smoke / Oak Green
- Frame
- Aluminum
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAluminum
Frameset
| Frame Construction | Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered head tube, threaded BB, UDH dropout |
|---|---|
| Frame Material | Aluminum |
| Fork | S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc |
| Fork Material | Carbon Fiber |
Drivetrain
| Shifters | SRAM APEX, 12sp |
|---|---|
| Rear Derailleur | SRAM APEX XPLR, Mechanical |
| Crankset | SRAM Apex Xplr, 40T |
| Bottom Bracket | SRAM DUB BSA 68 Wide |
| Cassette | SRAM PG 1231, Xplr, 11-44 |
| Chain | SRAM Apex 12S |
Brakes
| Brakes | (F) SRAM APEX, Hydraulic Disc / (R) SRAM APEX, Hydraulic Disc |
|---|
Cockpit & Contact Points
| Handlebar | Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare |
|---|---|
| Stem | Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
| Saddle | Body Geometry Power Sport, steel rails |
| Seatpost | Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware |
Wheels & Tires
| Wheels | (F) DT G540, Centerlock Disc, Tubeless Ready, 25mm internal width / (R) DT G540, Centerlock Disc, Tubeless Ready, 25mm internal width |
|---|---|
| Front Tire | Pathfinder Pro 2BR, 700x38 |
| Rear Tire | Pathfinder Pro 2BR, 700x38 |
No specifications match. Try a component name or clear your search.
Geometry
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
All geometry measurements6 sizes · 19 measurements
| Measurement | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Seat tube | 466 mm | 496 mm | 521 mm | 546 mm | 576 mm | 606 mm |
| Effective top tube | 512 mm | 539 mm | 549 mm | 568 mm | 582 mm | 599 mm |
| Head tube | 100 mm | 115 mm | 130 mm | 147 mm | 167 mm | 190 mm |
| Head-tube angle | 70.5° | 71.25° | 71.5° | 72° | 72.25° | 72.5° |
| Seat-tube angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73.5° |
| Chainstay / rear center | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1008 mm | 1014 mm | 1023 mm | 1033 mm | 1045 mm | 1059 mm |
| Bottom-bracket drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Bottom-bracket height | 284 mm | 284 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Reach | 375 mm | 382 mm | 388 mm | 397 mm | 405 mm | 415 mm |
| Stack | 530 mm | 547 mm | 560 mm | 578 mm | 598 mm | 621 mm |
| Standover height | 749 mm | 772 mm | 794 mm | 816 mm | 841 mm | 866 mm |
| Fork offset / rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Front center | 594 mm | 600 mm | 608 mm | 618 mm | 630 mm | 644 mm |
| Trail | 74 mm | 69 mm | 67 mm | 64 mm | 62 mm | 60 mm |
| Fork length / axle-to-crown | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm |
| Crank length | 170 mm | 170 mm | 172.5 mm | 172.5 mm | 175 mm | 175 mm |
| Stem length | 70 mm | 80 mm | 90 mm | 100 mm | 110 mm | 110 mm |
| Handlebar width | 380 mm | 400 mm | 420 mm | 420 mm | 440 mm | 440 mm |
Dimensions as recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
XPLR, 11-44

SRAM PG-1231 XPLR 12-Speed Cassette One Color, 11-44t
Model match
700x38
Replacement search: 700cx38 bicycle tire Before ordering: Check rim type and tire clearance.More parts (6)Fewer parts
40t
Mechanical
12sp
118.9mm drop x 70mm reach x 12º flare
2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Pathfinder Pro 2BR, 700x38
- Rear tire
- Pathfinder Pro 2BR, 700x38
- Drivetrain
- 12-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- SRAM DUB BSA 68 Wide
Equipment inspection checks 11 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered head tube, threaded BB, UDH dropout · Fork: S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM APEX, 12sp · Rear derailleur: SRAM APEX XPLR, Mechanical · Crankset: SRAM APEX XPLR, 40t · Bottom bracket: SRAM DUB BSA 68 Wide · Cassette: SRAM PG 1231, XPLR, 11-44 · Chain: SRAM APEX 12S
Brakes
Inspect the brakes →Archived: Brakes: (F) SRAM APEX, Hydraulic Disc / (R) SRAM APEX, Hydraulic Disc
Wheels and tires
Check wheels and tires →Archived: Wheels: (F) DT G540, Centerlock Disc, Tubeless Ready, 25mm internal width / (R) DT G540, Centerlock Disc, Tubeless Ready, 25mm internal width · Front tire: Pathfinder Pro 2BR, 700x38 · Rear tire: Pathfinder Pro 2BR, 700x38
Controls and contact points
Archived: Handlebar: Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare · Stem: Specialized, 3D-forged alloy, 4-bolt, 7-degree rise · Seatpost: Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware · Saddle: Body Geometry Power Sport, steel rails
