2002 Specialized Big Hit Comp

Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · Front: 26", Rear: 24" wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #37021
Model year
2002
Category
Mountain
Original MSRP
$2,700.00
Sizes
S, M, L
Colors
Satin
Geometry
Legacy reference
In this record
29 specifications · archived image · original MSRP · geometry
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2002 archived details

Published colors
Satin
Frame
Specialized A1 aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildSpecialized A1 aluminum · Mountain Mix · Front: 26", Rear: 24" wheels

Manufacturer catalog

Published sizes and colors

3 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SML

Published colors

Satin

Frameset

Frame ConstructionTIG-welded
Frame MaterialSpecialized A1 aluminum
ForkMarzocchi Z-5 QR20+
Fork MaterialAluminum, triple-clamp crown
Rear ShockFox Vanilla R, 5.30" - 6.30" adjustable travel

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore
Front DerailleurShimano Deore LX, bottom bracket mount
Rear DerailleurShimano Deore XT SGS
CranksetSpecialized BigArm II, 22/32/44 teeth
Bottom BracketTruVativ ISIS spline, 127.5mm spindle
BB Shell Width73mm English
Rear Cogs9-speed, 11 - 34 teeth
ChainShimano CN-HG53, 1/2 x 3/32"
PedalsShimano PD-M424 SPD

Brakes

BrakesHayes Hydraulic Disc brakes, Hayes Hydraulic Disc levers

Cockpit & Contact Points

Headset1 1/8" threadless Aheadset Tank
HandlebarSpecialized aluminum
Handlebar ExtensionsNot included
StemSpecialized riser
SaddleSpecialized BigHit
SeatpostAluminum, 30.9mm diameter

Wheels & Tires

HubsFront: Specialized Stout, Rear: Shimano Deore Disc
RimsSun Rims Single Track, 36-hole
SpokesDT stainless steel, 15ga. (1.8mm) straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.50" Specialized Roller Pro
Rear Tire24 x 2.50" Specialized Roller Pro
Wheel SizeFront: 26", Rear: 24" wheels

Geometry

Legacy reference · 3 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 3 measurements
MeasurementLegacy reference
Top tube585 mm
Chainstay / rear center429 mm
Wheelbase1125 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes44/32/22T · 11–34T · 9-speed
Lowest0.65:1 Highest4.00:1 Total range618%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
Shimano CN-HG53

1/2 x 3/32"

Front tire · Original
26 x 2.50" Specialized Roller Pro
More parts (7)Fewer parts
Rear tire · Original
24 x 2.50" Specialized Roller Pro
Pedals · Original
Shimano PD-M424 SPD
Saddle · Original
Specialized BigHit
Crankset · Original
Specialized BigArm II

22/32/44 teeth

Front derailleur · Original
Shimano Deore LX

bottom bracket mount

Rear derailleur · Original
Shimano Deore XT SGS
Shifters · Original
Shimano Deore

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Front: 26 x 2.50" Specialized Roller Pro, Rear: 24 x 2.50" Specialized Roller Pro
Drivetrain
9-speed
Seatpost diameter
30.9 mm
Bottom bracket / shell
TruVativ ISIS spline, 127.5mm spindle · 73mm English
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Marzocchi Z-5 QR20+ · Aluminum, triple-clamp crown

Archived: Fork: Marzocchi Z-5 QR20+ · Rear shock: Fox Vanilla R, 5.30" - 6.30" adjustable travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore · Front derailleur: Shimano Deore LX, bottom bracket mount · Rear derailleur: Shimano Deore XT SGS · Crankset: Specialized BigArm II, 22/32/44 teeth · Bottom bracket: TruVativ ISIS spline, 127.5mm spindle · Rear cogs: 9-speed, 11 - 34 teeth · Chain: Shimano CN-HG53, 1/2 x 3/32"

Archived: Brakes: Hayes Hydraulic Disc brakes, Hayes Hydraulic Disc levers

Archived: Wheel size: Front: 26", Rear: 24" wheels · Rims: Sun Rims Single Track, 36-hole · Hubs: Front: Specialized Stout, Rear: Shimano Deore Disc · Front tire: Front: 26 x 2.50" Specialized Roller Pro, Rear: 24 x 2.50" Specialized Roller Pro

Controls and contact points

Archived: Headset: 1 1/8" threadless Aheadset Tank · Handlebar: Specialized aluminum · Stem: Specialized riser · Seatpost: Aluminum, 30.9mm diameter · Saddle: Specialized BigHit · Pedals: Shimano PD-M424 SPD
