Velopedia Bicycle Archive

2013 Scott Plasma Premium

Original specifications.

Share owner experience

No archive photo is available for this record.

At a glance

Archive #9240453

Model year: 2013
Category: Road
Sizes: 52cm, 54cm, 56cm
Colors: Black/Gray
In this record: 17 specifications

Model history 3 other years

Browse other years

Compare side by side

Identification clues

2013 archived details

Published colors: Black/Gray
Frame: Carbon HMX NET

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildCarbon HMX NET

Manufacturer catalog

Published sizes and colors

3 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

52cm54cm56cm

Published colors

Black/Gray

Frameset

Frame Material	Carbon HMX NET
Fork	Plasma Carbon

Drivetrain

Shifters	SRAM Red
Front Derailleur	SRAM Red
Rear Derailleur	SRAM Red
Crankset	SRAM Red 53/39t
Bottom Bracket	Press Fit
Cassette	SRAM Red 11x25t
Rear Cogs	2x10 Speeds
Chain	SRAM Red

Brakes

Brakes	SRAM Red

Cockpit & Contact Points

Headset	1" Threadless
Handlebar	Profile Svet
Stem	Plasma 3
Saddle	Fizik Airone Tri2
Seatpost	Plasma 3

Wheels & Tires

Front Tire	Continental Competition

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes53/39T · 11–25T

Lowest1.56:1 Highest4.82:1 Total range309%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

SRAM Red

Search Amazon Search eBay

Cassette · Original

SRAM Red 11x25t

Search Amazon Search eBay

Saddle · Original

Fizik Airone Tri2

Search eBay

More parts (4)Fewer parts

Crankset · Original

SRAM Red 53/39t

Search eBay

Front derailleur · Original

SRAM Red Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.

Search eBay

Rear derailleur · Original

SRAM Red Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.

Search eBay

Shifters · Original

SRAM Red Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Continental Competition
Bottom bracket / shell: Press Fit

Equipment inspection checks 8 checks based on 4 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Carbon HMX NET · Fork: Plasma Carbon

Inspect the frame in bright light, especially the head tube, bottom-bracket area, chainstays and clamped surfaces. Look for cracks, ripples, crushed sections or signs of impact.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Shifters: SRAM Red · Front derailleur: SRAM Red · Rear derailleur: SRAM Red · Crankset: SRAM Red 53/39t · Bottom bracket: Press Fit · Cassette: SRAM Red 11x25t · Rear cogs: 2x10 Speeds · Chain: SRAM Red

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: SRAM Red

Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Controls and contact points

Archived: Headset: 1" Threadless · Handlebar: Profile Svet · Stem: Plasma 3 · Seatpost: Plasma 3 · Saddle: Fizik Airone Tri2

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
