Lowest0.93:1
Highest4.36:1
Total range468%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×32; rear size isn’t listed.
Velopedia Bicycle Archive
2006 Scott Sub 20 Classic
Original specifications: Shimano Deore · 8-speed · mechanical rear derailleur · 700c wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #94161- Model year
- 2006
- Category
- Hybrid
- Original MSRP
- $549.99
- In this record
- 24 specifications · original MSRP
Model history 4 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Frame
- Scott New Evo/Aero Alloy
- Original equipment
- Hybrid Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildScott New Evo/Aero Alloy · Hybrid Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Scott New Evo/Aero Alloy |
| Fork | Scott Straight Alloy |
| Fork Material | Aluminum, unicrown crown |
Drivetrain
| Component Group | Hybrid Mix |
|---|---|
| Shifters | Shimano Alivio |
| Front Derailleur | Shimano FD-T-301D |
| Rear Derailleur | Shimano Deore |
| Crankset | Shimano FC-TS80, 28/38/48 teeth |
| Bottom Bracket | Shimano BB-TS30 |
| Rear Cogs | 8-speed, 11 - 30 teeth |
| Chain | KMC Z72, 1/2 x 3/32" |
| Pedals | Wellgo LU-998-S |
Brakes
| Brakes | Tektro SCB-36A brakes, Scott Comp SCL-09 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated VP 41 AC E |
|---|---|
| Handlebar | Steel, riser |
| Stem | Aluminum threadless |
| Saddle | Velo VL 1061 SCT |
| Seatpost | Aluminum micro-adjust |
Wheels & Tires
| Hubs | Front: SCO 31 QR, Rear: Shimano FH-RM60 |
|---|---|
| Rims | Alesa DP 2000 |
| Spokes | DT Swiss stainless steel, 15ga. (1.8mm) straight gauge |
| Front Tire | 700 x 32c Maxxis Columbiere M-204 |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
KMC Z72
1/2 x 3/32"
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
KMC Z72 on eBaySponsored links
700 x 32c Maxxis Columbiere M-204
Retailer offers
Continental Ultra Sport Iii Road Bike Tire - 700C - (Clincher Wire) Black/Black, 700c x 32mm
700x32c
Replacement option
Other replacement options (1)
Challenge Strada Pro Tubeless Tire Tan, 700x32
700x32c
Replacement option
Maxxis Columbiere M 204 on eBaySponsored links
Shimano BB-TS30
More parts (4)Fewer parts
Wellgo LU-998-S
Shimano FC-TS80
28/38/48 teeth
Shimano Deore
Shimano Alivio
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 32c Maxxis Columbiere M-204
- Drivetrain
- 8-speed
- Bottom bracket / shell
- Shimano BB-TS30
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Scott Straight Alloy · Aluminum, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Hybrid Mix · Shifters: Shimano Alivio · Front derailleur: Shimano FD-T-301D · Rear derailleur: Shimano Deore · Crankset: Shimano FC-TS80, 28/38/48 teeth · Bottom bracket: Shimano BB-TS30 · Rear cogs: 8-speed, 11 - 30 teeth · Chain: KMC Z72, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro SCB-36A brakes, Scott Comp SCL-09 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alesa DP 2000 · Hubs: Front: SCO 31 QR, Rear: Shimano FH-RM60 · Front tire: 700 x 32c Maxxis Columbiere M-204
Controls and contact points
Archived: Headset: 1 1/8" integrated VP 41 AC E · Handlebar: Steel, riser · Stem: Aluminum threadless · Seatpost: Aluminum micro-adjust · Saddle: Velo VL 1061 SCT · Pedals: Wellgo LU-998-S
