Shimano Deore CN-M6100 Chain Silver, 12 Speed, 126 Links
12 Speed, 126 Links
Velopedia Bicycle Archive
Original specifications: 29" wheels · 29lb 13oz published weight · geometry for 5 published sizes.
Selling this bike? Create a shareable bike record
At a glance
| Frame Construction | Carbon |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | RockShox SID, 120mm |
| Shifters | Shimano Deore M6100, I-Spec EV |
|---|---|
| Rear Derailleur | Shimano Deore M6100-SGS |
| Crankset | Shimano Deore MT512, 32t; MRP 1x SL TR2 28-34t Direct Mount Guide |
| Bottom Bracket | Shimano MT500 Press-Fit |
| Cassette | Shimano Deore M6100, 10–51t, 12-speed |
| Chain | Shimano Deore M6100, HYPERGLIDE+ |
| Brakes | Brake Calipers: Shimano Deore MT-M410; Brake Levers: Shimano Deore M4100; Rotors: Shimano Deore RT64 (Center Lock, 180mm front and rear) |
|---|
| Headset | FSA Orbit 1.5E ZS NO.57E |
|---|---|
| Handlebar | Alloy riser |
| Stem | Salsa 35.0 Guide Trail, 50mm |
| Saddle | WTB Silverado, Medium, Cromoly, DNAx |
| Seatpost | TranzX YSI05 RAD+ Dropper Post w/ Shimano SL-MT500 I-Spec EV Lever, XS: 125mm travel; SM–MD: 150mm travel; LG–XL: 170mm travel |
| Hubs | (F) Shimano TC500-15-B 15x110mm / (R) Shimano TC500-MS-B 12x148mm |
|---|---|
| Rims | WTB KOM Team i30 TCS, 28h |
| Spokes | Butted stainless steel, black |
| Front Tire | Teravail Camrock 29x2.4", Light Trail casing, WTB TCS Sealant included |
| Rear Tire | Teravail Camrock 29x2.4", Light Trail casing, WTB TCS Sealant included |
| Wheel Size | 29" |
Frame measurements by size.
Published frame view
Select an available measurement to locate it on the frame.
| Measurement | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| Seat tube | 380 mm | 405 mm | 430 mm | 455 mm | 480 mm |
| Effective top tube | 567.8 mm | 584.9 mm | 606.9 mm | 629 mm | 651.1 mm |
| Head tube | 95 mm | 105 mm | 115 mm | 125 mm | 130 mm |
| Head-tube angle | 66.3- 66.0 | 66.3- 66.0 | 66.3- 66.0 | 66.3- 66.0 | 66.3- 66.0 |
| Seat-tube angle | 77.3- 77.0 | 77.3- 77.0 | 77.3- 77.0 | 77.3- 77.0 | 77.3- 77.0 |
| Chainstay / rear center | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1157 mm | 1176.1 mm | 1200 mm | 1224.1 mm | 1248.1 mm |
| Bottom-bracket drop | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm |
| Bottom-bracket height | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm |
| Reach | 435 mm | 450 mm | 470 mm | 490 mm | 510 mm |
| Stack | 589.3 mm | 598.4 mm | 607.6 mm | 616.7 mm | 625.9 mm |
| Standover height | 719.1 mm | 719.2 mm | 719.2 mm | 719.3 mm | 719.3 mm |
| Fork offset / rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork length / axle-to-crown | 530 mm | 530 mm | 530 mm | 530 mm | 530 mm |
| Crank length | 165 mm | 165 mm | 165 mm | 170 mm | 170 mm |
| Stem length | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
Measurements may vary by configuration, wheel size, or frame setting where noted in the published chart.
Parts & serviceability

12 Speed, 126 Links

10-51T
Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases.
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Archived: 2025 Salsa Spearfish C Deore 12 · Mountain · Published sizes: XS, S, M, L, XL
Archived: Frame: Carbon · Fork: RockShox SID, 120mm
Archived: Fork: RockShox SID, 120mm
Archived: Shifters: Shimano Deore M6100, I-Spec EV · Rear derailleur: Shimano Deore M6100-SGS · Crankset: Shimano Deore MT512, 32t; MRP 1x SL TR2 28-34t Direct Mount Guide · Bottom bracket: Shimano MT500 Press-Fit · Cassette: Shimano Deore M6100, 10–51t, 12-speed · Chain: Shimano Deore M6100, HYPERGLIDE+
Archived: Brakes: Brake Calipers: Shimano Deore MT-M410; Brake Levers: Shimano Deore M4100; Rotors: Shimano Deore RT64 (Center Lock, 180mm front and rear)
Archived: Wheel size: 29" · Rims: WTB KOM Team i30 TCS, 28h · Hubs: (F) Shimano TC500-15-B 15x110mm / (R) Shimano TC500-MS-B 12x148mm · Front tire: Teravail Camrock 29x2.4", Light Trail casing, WTB TCS Sealant included · Rear tire: Teravail Camrock 29x2.4", Light Trail casing, WTB TCS Sealant included
Archived: Headset: FSA Orbit 1.5E ZS NO.57E · Handlebar: Alloy riser · Stem: Salsa 35.0 Guide Trail, 50mm · Seatpost: TranzX YSI05 RAD+ Dropper Post w/ Shimano SL-MT500 I-Spec EV Lever, XS: 125mm travel; SM–MD: 150mm travel; LG–XL: 170mm travel · Saddle: WTB Silverado, Medium, Cromoly, DNAx
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
