Shimano SLX/105 CN-HG601 11-Speed Chain Grey, 126 Links
126 Links
Velopedia Bicycle Archive
Original specifications: 29" wheels · 46 lb for Medium published weight · geometry for 5 published sizes.
Selling this bike? Create a shareable bike record
At a glance
| Frame Construction | Aluminum |
|---|---|
| Frame Material | Aluminum |
| Fork | Carbon |
| Fork Material | Carbon Fiber |
| Shifters | Shimano GRX RX600 |
|---|---|
| Rear Derailleur | Shimano GRX RX812 |
| Crankset | FSA CK-762/IS |
| Cassette | Shimano Deore M5100 11-42T, 11-speed |
| Chain | Shimano HG601 |
| Brakes | Brake Calipers: Shimano RX400 hydraulic; Brake Levers: Shimano GRX RX600; Rotors: Shimano RT64 Center Lock (180mm front and rear) |
|---|
| Headset | Acros IS52/IS52 |
|---|---|
| Handlebar | Salsa Cowchipper |
| Stem | Easton EA50 |
| Saddle | WTB Volt Medium Steel |
| Seatpost | TranzX YSP18DL dropper, 100mm travel |
| Hubs | (F) Novatec D791SB-B15-CL / (R) Novatec D982TSB-CL-B12-11S |
|---|---|
| Rims | WTB ST 27mm |
| Spokes | 2.0, Black |
| Front Tire | Teravail Ehline 29 x 2.3", Durable casing |
| Rear Tire | Teravail Ehline 29 x 2.3", Durable casing |
| Wheel Size | 29" |
Frame measurements by size.
Published frame view
Select an available measurement to locate it on the frame.
| Measurement | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| Seat tube | 380 mm | 405 mm | 460 mm | 500 mm | 520 mm |
| Effective top tube | 535 mm | 560 mm | 585 mm | 610 mm | 635 mm |
| Head tube | 100 mm | 100 mm | 125 mm | 145 mm | 165 mm |
| Head-tube angle | 67° | 67° | 67° | 67° | 67° |
| Seat-tube angle | 75° | 75° | 75° | 75° | 75° |
| Chainstay / rear center | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1094 mm | 1119 mm | 1148 mm | 1176 mm | 1204 mm |
| Bottom-bracket drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom-bracket height | 303.5 mm | 303.5 mm | 303.5 mm | 303.5 mm | 303.5 mm |
| Reach | 373.7 mm | 398.7 mm | 417.6 mm | 437.6 mm | 457.7 mm |
| Stack | 601.8 mm | 601.8 mm | 624.8 mm | 643.2 mm | 661.7 mm |
| Standover height | 725.4 mm | 737.6 mm | 776.6 mm | 808.8 mm | 814.6 mm |
| Fork offset / rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork length / axle-to-crown | 498.4 mm | 498.4 mm | 498.4 mm | 498.4 mm | 498.4 mm |
| Crank length | 165 mm | 165 mm | 170 mm | 170 mm | 170 mm |
| Stem length | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
Measurements may vary by configuration, wheel size, or frame setting where noted in the published chart.
Parts & serviceability

126 Links

29x2.3
Replacement option · verify fit

Medium
Based on the original build. Confirm the model, size and fit before ordering; installed parts may differ. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases.
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Archived: 2024 Salsa Tributary GRX 600 · Electric-assist · Published sizes: XS, S, M, L, XL
Archived: Frame: Aluminum · Fork: Carbon · Carbon Fiber
Archived: Shifters: Shimano GRX RX600 · Rear derailleur: Shimano GRX RX812 · Crankset: FSA CK-762/IS · Cassette: Shimano Deore M5100 11-42T, 11-speed · Chain: Shimano HG601
Archived: Brakes: Brake Calipers: Shimano RX400 hydraulic; Brake Levers: Shimano GRX RX600; Rotors: Shimano RT64 Center Lock (180mm front and rear)
Archived: Wheel size: 29" · Rims: WTB ST 27mm · Hubs: (F) Novatec D791SB-B15-CL / (R) Novatec D982TSB-CL-B12-11S · Front tire: Teravail Ehline 29 x 2.3", Durable casing · Rear tire: Teravail Ehline 29 x 2.3", Durable casing
Archived: Headset: Acros IS52/IS52 · Handlebar: Salsa Cowchipper · Stem: Easton EA50 · Seatpost: TranzX YSP18DL dropper, 100mm travel · Saddle: WTB Volt Medium Steel
Archived: Salsa Tributary GRX 600 · electric-assist identification
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
