Velopedia Bicycle Archive
2024 Salsa Confluence Flat Bar Altus
Electric-assist bicycle from the Velopedia specification archive.
Selling this bike? Create a Bike History Report
- Original MSRP
- $2,699.00
- Sizes
- XS, S, M, L, XL
- Colors
- Black
- Weight
- 32.5 lb (Large frame)
- Geometry
- 5 manufacturer sizes · Ride analysis
- Archive ID
- 900000622
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Velopedia analysis
What the specifications mean
The electric-assist system adds another maintenance layer, especially battery condition, charger compatibility, motor operation and any available diagnostic history. The 327% cassette range describes the available gearing more clearly than the component-group name alone. On the alloy frame, dents and hairline cracks around welds matter more than cosmetic scratches. Pay closest attention near the head tube, bottom bracket shell, dropouts and other heavily loaded junctions.
E-bike system
Electric-assist
The drive system needs its own battery, charger, motor-control and diagnostic checks in addition to the bicycle components.
Gearing
327% cassette range
Calculated from the published 11–36-tooth sprocket span.
Frame material
Aluminum / alloy
Dents and cracking around welds at the head tube, bottom bracket shell and dropouts deserve attention.
Wheel standard
700C · 622 mm
The label fixes rim diameter, not tire width or available frame and fork clearance.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- E-bike systemConfirm the main battery charges with the correct charger, locks securely into its mount and has no case damage, swelling, corrosion or overheating marks. Power the bike on from cold, test every assist mode and ask for available battery-health and diagnostic records.Check the battery and electronics →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 23 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2024 Salsa Confluence Flat Bar Altus · Electric-assist · Published sizes: XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Aluminum · Fork: Carbon · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano Altus M2010 · Rear derailleur: Shimano Altus M2000 · Crankset: FSA Vero Pro, 40t · Bottom bracket: RPM Cartridge Bottom Bracket · Cassette: Shimano HG200-9, 9-speed, 11–36t · Chain: KMC Z9
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: Tektro MD-U510/MD-U310; Brake Levers: Tektro RS360A; Rotors: Tektro TR160-22, 160 mm, 6-bolt
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700C · Rims: WTB ST i23, 32h · Hubs: (F) WTB Serra / (R) MAHLE X35+ · Front tire: Teravail Washburn 700c x 42mm, Durable casing, wire bead · Rear tire: Teravail Washburn 700c x 42mm, Durable casing, wire bead
Controls and contact points
Archived: Headset: FSA · Handlebar: Salsa Salt Flat · Stem: Salsa Guide · Seatpost: Promax SP-2016 · Saddle: WTB Volt
E-bike system
Check the battery and electronics →Archived: Salsa Confluence Flat Bar Altus · electric-assist identification
Before and during the test ride
Follow the full used-bike inspection order →Interpretation based on the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | Aluminum |
|---|---|
| Frame Material | Aluminum |
| Fork | Carbon |
| Fork Material | Carbon Fiber |
Drivetrain
| Shifters | Shimano Altus M2010 |
|---|---|
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Altus M2000 |
| Crankset | FSA Vero Pro, 40t |
| Bottom Bracket | RPM Cartridge Bottom Bracket |
| Cassette | Shimano HG200-9, 9-speed, 11–36t |
| Chain | KMC Z9 |
Brakes
| Brakes | Brake Calipers: Tektro MD-U510/MD-U310; Brake Levers: Tektro RS360A; Rotors: Tektro TR160-22, 160 mm, 6-bolt |
|---|
Cockpit & Contact Points
| Headset | FSA |
|---|---|
| Handlebar | Salsa Salt Flat |
| Stem | Salsa Guide |
| Saddle | WTB Volt |
| Seatpost | Promax SP-2016 |
Wheels & Tires
| Hubs | (F) WTB Serra / (R) MAHLE X35+ |
|---|---|
| Rims | WTB ST i23, 32h |
| Spokes | Straight gauge, black |
| Front Tire | Teravail Washburn 700c x 42mm, Durable casing, wire bead |
| Rear Tire | Teravail Washburn 700c x 42mm, Durable casing, wire bead |
| Wheel Size | 700C |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| Seat tube | 340 mm | 380 mm | 450 mm | 490 mm | 530 mm |
| Effective top tube | 550 mm | 570 mm | 600 mm | 625 mm | 650 mm |
| Head tube | 90 mm | 120 mm | 160 mm | 200 mm | 240 mm |
| Head-tube angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
| Seat-tube angle | 73° | 73° | 73° | 73° | 73° |
| Chainstay / rear center | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1056 mm | 1078 mm | 1111 mm | 1140 mm | 1168 mm |
| Bottom-bracket drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Reach | 394 mm | 406 mm | 424 mm | 438 mm | 451 mm |
| Stack | 510 mm | 538 mm | 575 mm | 613 mm | 650 mm |
| Standover height | 622 mm | 659 mm | 721 mm | 761 mm | 800 mm |
| Fork offset / rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Fork length / axle-to-crown | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Crank length | 165 mm | 170 mm | 172.5 mm | 172.5 mm | 175 mm |
| Stem length | 60 mm | 70 mm | 70 mm | 80 mm | 90 mm |
Geometry source: Salsa first-party metric geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry interpretation
What this geometry means
X-Small geometry
Riding position
At 394 mm of reach and 510 mm of stack, the frame is longer relative to its height, which generally creates more potential for a stretched, lower-front-end position.
Handling tendencies
A 68.5° head angle combined with a 1056 mm wheelbase points to more stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Small geometry
Riding position
At 406 mm of reach and 538 mm of stack, the frame is longer relative to its height, which generally creates more potential for a stretched, lower-front-end position.
Handling tendencies
A 68.5° head angle combined with a 1078 mm wheelbase points to more stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Medium geometry
Riding position
At 424 mm of reach and 575 mm of stack, the frame is longer relative to its height, which generally creates more potential for a stretched, lower-front-end position.
Handling tendencies
A 68.5° head angle combined with a 1111 mm wheelbase points to more stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Large geometry
Riding position
The 438 mm reach and 613 mm stack sit in a moderate proportion, without a strong long-and-low or tall-and-short bias.
Handling tendencies
A 68.5° head angle combined with a 1140 mm wheelbase points to more stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
X-Large geometry
Riding position
The 451 mm reach and 650 mm stack sit in a moderate proportion, without a strong long-and-low or tall-and-short bias.
Handling tendencies
A 68.5° head angle combined with a 1168 mm wheelbase points to more stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Across the size range
From X-Small to X-Large, reach grows by 57 mm and stack by 140 mm, showing how the frame becomes both longer and taller through the published size range. The rear center stays essentially constant at about 440 mm across sizes, so most of the wheelbase growth happens in the front half of the bike rather than by lengthening the rear triangle.
Geometry describes frame proportions and likely tendencies, not a ride test. Rider proportions, cockpit setup, tires, suspension settings, wheel configuration, and component choices can materially change how a bicycle fits and feels.
Gallery
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
