Uses front tire 20×1.95; rear size isn’t listed.
Velopedia Bicycle Archive
2009 Redline RL 3.2
Original specifications: BMX drivetrain · 20" wheels · 35 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #15934- Model year
- 2009
- Category
- BMX
- Colors
- Black, Brown/Orange
- Weight
- 35 lb
- In this record
- 22 specifications · archived image
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2009 archived details
- Published colors
- Black, Brown/Orange
- Frame
- Chromoly main triangle
- Original equipment
- BMX
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildChromoly main triangle · BMX · 20" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Chromoly main triangle |
| Fork | Redline Monster |
| Fork Material | Chromoly/Hi-ten, unicrown crown |
Drivetrain
| Component Group | BMX |
|---|---|
| Crankset | Redline Monster Tubular Cr-mo, 33 teeth |
| Bottom Bracket | Mid BB |
| Cassette | Redline |
| Rear Cogs | 1-speed, 12 teeth |
| Chain | KMC Z410, 1/2 x 1/8" |
| Pedals | Redline Aluminum |
Brakes
| Brakes | Tektro FX-340 U-brake rear brakes, Tektro 273A hinged rear levers |
|---|
Cockpit & Contact Points
| Headset | VP threadless |
|---|---|
| Handlebar | Redline Hi-Ten |
| Handlebar Extensions | Not included |
| Stem | Redline Proline |
| Saddle | Redline Park Bench |
| Seatpost | Redline, 25.4mm diameter |
Wheels & Tires
| Hubs | Front: Redline Aluminum 14mm, Rear: Redline Cassette Aluminum |
|---|---|
| Rims | Alienation PBR, 48-hole |
| Front Tire | 20 x 1.95" Redline Freaky-X |
| Wheel Size | 20" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
25.4mm diameter
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 20 x 1.95" Redline Freaky-X
- Drivetrain
- 1-speed
- Seatpost diameter
- 25.4 mm
- Bottom bracket / shell
- Mid BB
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Redline Monster · Chromoly/Hi-ten, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: BMX · Crankset: Redline Monster Tubular Cr-mo, 33 teeth · Bottom bracket: Mid BB · Cassette: Redline · Rear cogs: 1-speed, 12 teeth · Chain: KMC Z410, 1/2 x 1/8"
Brakes
Inspect the brakes →Archived: Brakes: Tektro FX-340 U-brake rear brakes, Tektro 273A hinged rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 20" wheels · Rims: Alienation PBR, 48-hole · Hubs: Front: Redline Aluminum 14mm, Rear: Redline Cassette Aluminum · Front tire: 20 x 1.95" Redline Freaky-X
Controls and contact points
Archived: Headset: VP threadless · Handlebar: Redline Hi-Ten · Stem: Redline Proline · Seatpost: Redline, 25.4mm diameter · Saddle: Redline Park Bench · Pedals: Redline Aluminum
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
