Lowest0.88:1
Highest4.36:1
Total range499%
Velopedia Bicycle Archive
At a glance
Archive #2029865- Model year
- 2012
- Category
- Hybrid
- Original MSRP
- $530.00
- Sizes
- S, M, L, XL
- Colors
- Black
- In this record
- 18 specifications · 2 archived images · original MSRP
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2012 archived details
- Published colors
- Black
- Frame
- Atomic 13 SL Aluminum
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAtomic 13 SL Aluminum
Frameset
| Frame Material | Atomic 13 SL Aluminum |
|---|---|
| Fork | 4130 Chromoly |
Drivetrain
| Shifters | Shimano EF-51 8spd |
|---|---|
| Front Derailleur | Shimano Altus |
| Rear Derailleur | Shimano Acera 8spd |
| Crankset | Shimano M131 48/38/28t |
| Bottom Bracket | sealed cartridge |
| Cassette | Shimano HG40 11-32t |
| Chain | Shimano HG40 |
| Pedals | Wellgo M21 |
Brakes
| Brakes | Tektro Novella 160mm |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless |
|---|---|
| Handlebar | Avenir 100 Series 15mm Riser |
| Stem | Avenir 100 Series 31.8mm |
| Saddle | Avenir 200 Series Mountain |
| Seatpost | Alloy 27.2 |
Wheels & Tires
| Rims | Weinmann XC260 |
|---|---|
| Front Tire | Kenda K-192 700 X 38c |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano HG40
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Shimano CN-HG40 on eBaySponsored links
Shimano HG40 11-32t
Kenda K-192 700 X 38c
Replacement search: 700cx38 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (4)Fewer parts
Wellgo M21
Shimano M131 48/38/28t
Shimano Altus
Shimano Acera 8spd
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Kenda K-192 700 X 38c
- Drivetrain
- 8-speed
- Bottom bracket / shell
- sealed cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Atomic 13 SL Aluminum · Fork: 4130 Chromoly
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano EF-51 8spd · Front derailleur: Shimano Altus · Rear derailleur: Shimano Acera 8spd · Crankset: Shimano M131 48/38/28t · Bottom bracket: sealed cartridge · Cassette: Shimano HG40 11-32t · Chain: Shimano HG40
Brakes
Inspect the brakes →Archived: Brakes: Tektro Novella 160mm
Wheels and tires
Check wheels and tires →Archived: Rims: Weinmann XC260 · Front tire: Kenda K-192 700 X 38c
Controls and contact points
Archived: Headset: 1 1/8" threadless · Handlebar: Avenir 100 Series 15mm Riser · Stem: Avenir 100 Series 31.8mm · Seatpost: Alloy 27.2 · Saddle: Avenir 200 Series Mountain · Pedals: Wellgo M21
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery2 images
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
