Lowest0.88:1
Highest4.36:1
Total range499%
Velopedia Bicycle Archive
At a glance
Archive #2007077- Model year
- 2012
- Category
- Hybrid
- Original MSRP
- $600.00
- Sizes
- 45cm, 49cm, 52cm, 54cm, 56cm
- Colors
- Silver/Green
- In this record
- 18 specifications · 2 archived images · original MSRP
Model history 4 other years
Browse other years
Compare side by side
Identification clues
2012 archived details
- Published colors
- Silver/Green
- Frame
- Atomic 13 SL Hydroformed AL
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAtomic 13 SL Hydroformed AL
Frameset
| Frame Material | Atomic 13 SL Hydroformed AL |
|---|---|
| Fork | Alloy Cross |
Drivetrain
| Shifters | Shimano EF-51 8spd |
|---|---|
| Front Derailleur | Shimano Altus |
| Rear Derailleur | Shimano Alivio 8spd |
| Crankset | Shimano M311 48/38/28t |
| Bottom Bracket | sealed cartridge |
| Cassette | SRAM PG-830 11-32T |
| Chain | KMC Z-82 |
| Pedals | resin body w/ toe clips |
Brakes
| Brakes | Tektro Alloy Mini V-Brake |
|---|
Cockpit & Contact Points
| Headset | Integrated 1-1/8" threadless |
|---|---|
| Handlebar | Avenir 200 Series Flat |
| Stem | Avenir 200 Series 31.8mm |
| Saddle | Avenir 200 Series Womens Road |
| Seatpost | Avenir 100 Series 31.6mm |
Wheels & Tires
| Hubs | Joytech Alloy Shimano RM30 |
|---|---|
| Front Tire | Vittoria Randonneur 700x32c |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
KMC Z-82
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Vittoria Randonneur 700x32c
Retailer offers
Goodyear Eagle Tubeless Tire Black, 700x32
700x32c
Replacement option
Other replacement options (1)
Challenge Strada Pro Tubeless Tire Tan, 700x32
700x32c
Replacement option
Vittoria Randonneur on eBaySponsored links
Avenir 100 Series 31.6mm
Retailer offers
FSA Gossamer SB20 Seatpost Black, 31.6mm, 350mm
Replacement option
More parts (6)Fewer parts
Tektro Alloy Mini V-Brake
Shimano M311 48/38/28t
Shimano Altus
Shimano Alivio 8spd
Joytech Alloy Shimano RM30
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Vittoria Randonneur 700x32c
- Drivetrain
- 8-speed
- Seatpost diameter
- 31.6 mm
- Bottom bracket / shell
- sealed cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Atomic 13 SL Hydroformed AL · Fork: Alloy Cross
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano EF-51 8spd · Front derailleur: Shimano Altus · Rear derailleur: Shimano Alivio 8spd · Crankset: Shimano M311 48/38/28t · Bottom bracket: sealed cartridge · Cassette: SRAM PG-830 11-32t · Chain: KMC Z-82
Brakes
Inspect the brakes →Archived: Brakes: Tektro Alloy Mini V-Brake
Wheels and tires
Check wheels and tires →Archived: Hubs: Joytech Alloy Shimano RM30 · Front tire: Vittoria Randonneur 700x32c
Controls and contact points
Archived: Headset: Integrated 1-1/8" threadless · Handlebar: Avenir 200 Series Flat · Stem: Avenir 200 Series 31.8mm · Seatpost: Avenir 100 Series 31.6mm · Saddle: Avenir 200 Series Womens Road · Pedals: resin body w/ toe clips
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery2 images
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
