2002 Raleigh R700T
Road race & triathlon bicycle from the Velopedia specification archive.
- Original MSRP
- $1,699.99
- Sizes
- 47cm, 50cm, 53cm, 56cm, 59cm, 62cm
- Colors
- Red/Black
- Archive ID
- 91307
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 aluminum w/replaceable derailleur hanger |
| Fork | Kinesis |
| Fork Material | Carbon fiber composite, aero crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Shimano Ultegra Triple |
|---|---|
| Shifters | Shimano Ultegra STI Dual Control |
| Front Derailleur | Shimano Ultegra Triple, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Ultegra GS |
| Crankset | Shimano Ultegra Triple, 30/42/52 teeth |
| Bottom Bracket | Shimano BB-5500, 118.5mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 23 teeth |
| Chain | Shimano CN-HG72, 1/2 x 3/32" |
| Pedals | Wellgo WPD-R4 clipless |
Brakes
| Brakes | Shimano Ultegra Dual Pivot brakes, Shimano Ultegra levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Tien Hsin No.10 ZST |
|---|---|
| Handlebar | ITM Mantjs |
| Handlebar Extensions | N/A |
| Stem | ITM Mantjs |
| Saddle | Selle Italia ProLink w/carbon rails |
| Seatpost | Aluminum micro-adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano 105 |
|---|---|
| Rims | Shimano WH-R535, 16-hole |
| Spokes | Shimano stainless steel, 14ga. (2.0mm) bladed |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 23c Michelin Axial Pro |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
