Velopedia Bicycle Archive

2000 Raleigh M800

Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · 26" wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #90278
Model year
2000
Category
Mountain
Original MSRP
$1,100.00
Sizes
14", 16", 18", 20", 22"
Colors
Liquid Green
Geometry
Legacy reference
In this record
27 specifications · original MSRP · geometry
Model history 6 other years

Browse other years

Compare side by side

Identification clues

2000 archived details

Published colors
Liquid Green
Frame
7005 aluminum, butted w/replaceable derailleur hanger
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build7005 aluminum, butted w/replaceable derailleur hanger · Mountain Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

14"16"18"20"22"

Published colors

Liquid Green

Frameset

Frame ConstructionTIG-welded
Frame Material7005 aluminum, butted w/replaceable derailleur hanger
ForkRock Shox Judy Race, 2.5"-4.0" adjustable travel
Fork MaterialAluminum/magnesium, triple-clamp crown

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore LX
Front DerailleurShimano Deore LX, top-pull/clamp-on 31.8mm
Rear DerailleurShimano Deore XT SGS
CranksetShimano Deore LX, 22/32/44 teeth
Bottom BracketShimano BB-ES70, 113mm spindle
BB Shell Width68mm English
Rear Cogs9-speed, 11 - 32 teeth
ChainKMC Z9200, 1/2 x 3/32"
PedalsWellgo WPD-813 clipless

Brakes

BrakesDia Tech mechanical disc brakes, Avid SD-1.9 L levers

Cockpit & Contact Points

Headset1 1/8" threadless WTB Momentum Comp ST
HandlebarKoski
Handlebar ExtensionsAlloy
StemKoski Forged Alloy
SaddleWTB SST.XCZ
SeatpostAluminum, suspension, 27.2mm diameter

Wheels & Tires

HubsFormula disc
RimsMavic X223 Disc, 32-hole
SpokesChung Nan stainless steel, 2.0mm straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.10" IRC Notos XC
Wheel Size26" wheels

Geometry

Legacy reference · 5 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 5 measurements
MeasurementLegacy reference
Top tube584.2 mm
Head-tube angle71°
Seat-tube angle73°
Chainstay / rear center424.2 mm
Wheelbase1056.6 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes44/32/22T · 11–32T · 9-speed
Lowest0.69:1 Highest4.00:1 Total range582%
Estimated speed At 90 RPM Lowest gear4.8 mph Highest gear28.1 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Seatpost · Original
Aluminum

suspension, 27.2mm diameter

Retailer offers
Front tire · Original
26 x 2.10" IRC Notos XC
Bottom bracket · Original
Shimano BB-ES70

113mm spindle

More parts (7)Fewer parts
Pedals · Original
Wellgo WPD-813 clipless
Saddle · Original
WTB SST.XCZ
Crankset · Original
Shimano Deore LX

22/32/44 teeth

Rear derailleur · Original
Shimano Deore XT SGS
Shifters · Original
Shimano Deore LX
Headset · Original
1 1/8" threadless WTB Momentum Comp ST
Rims · Original
Mavic X223 Disc

32-hole

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" IRC Notos XC
Drivetrain
9-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Shimano BB-ES70, 113mm spindle · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Rock Shox Judy Race, 2.5"-4.0" adjustable travel · Aluminum/magnesium, triple-clamp crown

Archived: Fork: Rock Shox Judy Race, 2.5"-4.0" adjustable travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore LX · Front derailleur: Shimano Deore LX, top-pull/clamp-on 31.8mm · Rear derailleur: Shimano Deore XT SGS · Crankset: Shimano Deore LX, 22/32/44 teeth · Bottom bracket: Shimano BB-ES70, 113mm spindle · Rear cogs: 9-speed, 11 - 32 teeth · Chain: KMC Z9200, 1/2 x 3/32"

Archived: Brakes: Dia Tech mechanical disc brakes, Avid SD-1.9 L levers

Archived: Wheel size: 26" wheels · Rims: Mavic X223 Disc, 32-hole · Hubs: Formula disc · Front tire: 26 x 2.10" IRC Notos XC

Controls and contact points

Archived: Headset: 1 1/8" threadless WTB Momentum Comp ST · Handlebar: Koski · Stem: Koski Forged Alloy · Seatpost: Aluminum, suspension, 27.2mm diameter · Saddle: WTB SST.XCZ · Pedals: Wellgo WPD-813 clipless
